28 ZT Eurocomach excavator specs & dimensions (2020 - 2023)

Eurocomach 28 ZT is a mini excavator manufactured since 2020, with a weight of 3.02 tons. It features a track width of 280 mm, a t…

Eurocomach 28 ZT is a mini excavator manufactured since 2020, with a weight of 3.02 tons. It features a track width of 280 mm, a transport length of 4.66 meters, a transport width of 1.55 meters, and a transport height of 2.53 meters. The machine has a tear-out force of 35 kN, a dredging depth of 2.65 meters, and a maximum horizontal reach of 4.72 meters. Special equipment includes air conditioning, a blade, hydraulic quick hitch, mechanical quick hitch, and rubber tracks.

28 ZT

Years of manufacture: 2020—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 28 ZT Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.02 t

Transport length: 4.66 m

Transport width: 1.55 m

Transport height: 2.53 m

Track width: 280 mm

Driver protection: KbR

Max. Reach horizontal: 4.72 m

Dredging depth: 2.65 m

Tear-out force: 35 kN

Model series: MME

Engine manuf.: Kubota

Engine type: D1703-M

Engine power: 18.2 kW

Displacement: 1.647 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

Eurocomach 28 ZT FAQ

When was the Eurocomach 28 ZT manufactured?

The Eurocomach 28 ZT was manufactured from 2020 to 2023.

How much does the Eurocomach 28 ZT weigh?

The Eurocomach 28 ZT weighs 3.02 tons.

What are the transport dimensions of the Eurocomach 28 ZT mini excavator?

The Eurocomach 28 ZT has a transport length of 4.66 meters, a transport width of 1.55 meters, and a transport height of 2.53 meters.

What is the track width of the Eurocomach 28 ZT mini excavator?

The Eurocomach 28 ZT mini excavator has a track width of 280 mm.

What are the excavation performance specifications of the Eurocomach 28 ZT mini excavator?

The Eurocomach 28 ZT mini excavator has a dredging depth of 2.65 meters and a maximum horizontal reach of 4.72 meters.

What is the tear-out force of the Eurocomach 28 ZT mini excavator?

The Eurocomach 28 ZT mini excavator has a tear-out force of 35 kN.

What operator safety and support features does the Eurocomach 28 ZT have?

The Eurocomach 28 ZT is equipped with a cabin that includes ROPS for driver protection.

How much is a Eurocomach 28 ZT Mini excavator (2020u20132023) worth?

The residual value of the Eurocomach 28 ZT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach 28 ZT overview

Dimensions and weight

Circuit Type	Load Sensing closed center system with “Flow Sharing” control valve
Pump type	1 LS variable pump + 1 gear pump
Pump displacement	cc	48 + 5
Pump capacity	lt/min	105 + 10
Max. circuit calibration pressure	bar	250
Auxiliary systems (max pressure): AUX 1 single or double effect with priority AUX 2 double effect (optional)	lt/min (bar)	50 (200) 35/20 (250)
PERFORMANCES
Max. digging depth with standard arm (optional arm)	mm	2.650 (2.850)
Max. dumping height with standard arm (optional arm)	mm	3.100 (3.220)
Bucket breaking force (standard arm) ISO 6015	daN	3.500
Arm breaking force (standard arm) ISO 6015	daN	1.750
Traction force	daN	3.400
Ground bearing pressure with rubber tracks and canopy (with cabin)	kg/cm2	0	29 (0	31)"

Tables

	3	4	MAX
Frontal and lowered dozer blade	*890	*680	*670
Frontal and lifted dozer blade	600	390	www.eurocomach.com305 380
Lateral	420	280	270

Cooling		Liquid
Consumption	lt/h	3	5"
Alternator	V (A)	12 (40)
Battery	V (Ah)	12 (80)
