25sa Eurocomach excavator specs & dimensions (2022 - 2023)

Menzi 25sa is a mini excavator manufactured since 2022. It has a weight of 2.41 tons and a track width of 280 mm. The transport di…

Menzi 25sa is a mini excavator manufactured since 2022. It has a weight of 2.41 tons and a track width of 280 mm. The transport dimensions are 4.515 meters in length, 1.5 meters in width, and 2.527 meters in height. The machine features a tear-out force of 22 kN, a dredging depth of 2.725 meters, and a maximum horizontal reach of 4.62 meters. Special equipment includes a blade and rubber tracks.

25sa

Years of manufacture: 2022—2023

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 25sa Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.41 t

Transport length: 4.515 m

Transport width: 1.5 m

Transport height: 2.527 m

Track width: 280 mm

Driver protection: FD

Max. Reach horizontal: 4.62 m

Dredging depth: 2.725 m

Tear-out force: 22 kN

Engine manuf.: Yanmar

Engine type: 3TNV76

Engine power: 15.5 kW

Displacement: 1.116 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Eurocomach 25sa FAQ

When was the Eurocomach 25sa manufactured?

The Eurocomach 25sa was manufactured from 2022 to 2023.

How much does the Eurocomach 25sa weigh?

The Eurocomach 25sa weighs 2.41 tons.

What are the transport dimensions of the Eurocomach 25sa mini excavator?

The Eurocomach 25sa has a transport length of 4.52 meters, a transport width of 1.5 meters, and a transport height of 2.53 meters.

What is the track width of the Eurocomach 25sa mini excavator's undercarriage?

The Eurocomach 25sa mini excavator has a track width of 280 mm.

What are the dredging depth and maximum horizontal reach of the Eurocomach 25sa mini excavator?

The Eurocomach 25sa mini excavator has a dredging depth of 2.725 meters and a maximum horizontal reach of 4.62 meters.

What is the tear-out force of the Eurocomach 25sa mini excavator?

The Eurocomach 25sa mini excavator has a tear-out force of 22 kN.

What operator safety and support features does the Eurocomach 25sa have?

The Eurocomach 25sa is equipped with a canopy for driver protection.

How much is a Eurocomach 25sa Mini excavator (2022u20132023) worth?

The residual value of the Eurocomach 25sa depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
