24 SR Eurocomach excavator specs & dimensions (2019 - 2020)

Eurocomach 24 SR is a mini excavator manufactured from 2019 to 2020, with a weight of 2.23 tons. It features a track width of 250 …

Eurocomach 24 SR is a mini excavator manufactured from 2019 to 2020, with a weight of 2.23 tons. It features a track width of 250 mm, a transport length of 3.834 meters, a transport width of 1.45 meters, and a transport height of 2.395 meters. The machine has a tear-out force of 22 kN, a dredging depth of 2.493 meters, and a maximum horizontal reach of 4.418 meters. Special equipment includes a blade, quick hitch hydraulic, and rubber tracks.

24 SR

Years of manufacture: 2019—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 24 SR Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.23 t

Transport length: 3.834 m

Transport width: 1.45 m

Transport height: 2.395 m

Track width: 250 mm

Driver protection: FD

Max. Reach horizontal: 4.418 m

Dredging depth: 2.493 m

Tear-out force: 22 kN

Model series: MME

Engine manuf.: Yanmar

Engine type: 3TNV76

Engine power: 14 kW

Displacement: 1.116 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Eurocomach 24 SR FAQ

When was the Eurocomach 24 SR manufactured?

The Eurocomach 24 SR was manufactured from 2019 to 2020.

How much does the Eurocomach 24 SR weigh?

The Eurocomach 24 SR weighs 2.23 tons.

What are the transport dimensions of the Eurocomach 24 SR mini excavator?

The Eurocomach 24 SR has a transport length of 3.83 meters, a transport width of 1.45 meters, and a transport height of 2.4 meters.

What is the track width of the Eurocomach 24 SR's undercarriage?

The Eurocomach 24 SR has a track width of 250 mm.

What is the excavation performance of the Eurocomach 24 SR mini excavator?

The Eurocomach 24 SR mini excavator has a dredging depth of 2.493 meters and a maximum horizontal reach of 4.418 meters.

What is the tear-out force of the Eurocomach 24 SR mini excavator?

The Eurocomach 24 SR mini excavator has a tear-out force of 22 kN.

What operator safety and support features does the Eurocomach 24 SR have?

The Eurocomach 24 SR is equipped with a canopy for driver protection.

How much is a Eurocomach 24 SR Mini excavator (2019u20132020) worth?

The residual value of the Eurocomach 24 SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach 24 SR overview

Dimensions and weight

HYDRAULIC SYSTEM
Pump type	variable flow
Pump displacement	cc 2 x 13 + 8	3"
Pump capacity	lt/min	2 x 26	5+17"
Max. circuit calibration pressure	bar		230
Auxiliary system: Max capacity	lt/min		40
Max pressure	bar		210
PERFORMANCES
Max digging depth standard arm (optional arm)	mm		2.493 (2.693)
Max dumping height with canopy standard arm (optional arm)	mm		2.967 (3.106)
Max dumping height with cab standard arm (optional arm)	mm		2.836 (2.957)
Bucket breaking force (standard arm) ISO 6015	daN		2.200
Arm breaking force (standard arm) ISO 6015	daN		1.520
Traction force	daN	2.000
Ground bearing pressure with rubber tracks and canopy (with cabin)	kg/cm2	0	26 (0	28)"
Max slope		60% - 30°
DIMENSIONS
Maximum width	mm	1.450
Total height	mm	2.395
Rear rotation radius	mm	750
Digging arm length std (optional)	mm	1.150 (1.350)
Tracks width	mm		250
Rollers number (for each side)	n°	4
FILLINGS
Fuel tank	lt	26
Hydraulic oil tank	lt	29
Hydraulic circuit capacity	lt	40
Cooling system capacity	lt	5
Engine oil	lt	2	8"
CONTROLS

Tables

	2	2	5"	3	3	5"	MAX
Frontal and lowered dozer blade	948	661	531	457	431
Frontal and lifted dozer blade	788	544	413	323	293
Lateral	593	424	319	251	225

Boom	dipper stick	bucket and turret swing"	2 pilot joysticks
Track movements (included counter rotation)	2 pilot levers
Dozer blade	pilot lever
Auxiliary circuit (simple or double effect)	electroproportional switch on right joystick
Boom swing	electroproportional switch on left joystick
