Technical specs - 18 ZT Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.73 t

Transport length: 3.3 m

Transport width: 0.99 m

Transport height: 2.357 m

Track width: 230 mm

Driver protection: KbR

Max. Reach horizontal: 3.8 m

Dredging depth: 2.3 m

Tear-out force: 15.5 kN

Model series: MME

Engine manuf.: Yanmar

Engine type: 3TNV70

Engine power: 11.2 kW

Displacement: 0.854 l

Revolutions at max torque: 2100 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Eurocomach 18 ZT FAQ

When was the Eurocomach 18 ZT manufactured?

The Eurocomach 18 ZT was manufactured from 2019 to 2022.

How much does the Eurocomach 18 ZT weigh?

The Eurocomach 18 ZT weighs 1.73 tons.

What are the transport dimensions of the Eurocomach 18 ZT mini excavator?

The Eurocomach 18 ZT has a transport length of 3.3 meters, a transport width of 0.99 meters, and a transport height of 2.36 meters.

What is the track width of the Eurocomach 18 ZT mini excavator?

The Eurocomach 18 ZT mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Eurocomach 18 ZT mini excavator?

The Eurocomach 18 ZT mini excavator has a dredging depth of 2.3 meters and a maximum horizontal reach of 3.8 meters.

What is the tear-out force of the Eurocomach 18 ZT mini excavator?

The Eurocomach 18 ZT mini excavator has a tear-out force of 15.5 kN.

What operator safety features does the Eurocomach 18 ZT have?

The Eurocomach 18 ZT has driver protection in the form of a cabin with ROPS.

How much is a Eurocomach 18 ZT Mini excavator (2019u20132022) worth?

The residual value of the Eurocomach 18 ZT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Eurocomach 18 ZT overview

Engine / Driveline and transmission

The rear engine compartment provides easy access to all filters of the heat motor (fuel, oil and air) as well as a simple replenishment of cooling fluid and engine oil. All access points for daily checks and routine maintenance are easily accessible and concentrated in defined areas optimize machine downtime. The battery, fuses and hydraulic oil above can be reached through special compartments at the front of the driver's location. ZUSCHSIBILITY Common or dedicated access areas facilitate any maintenance quickly and easily.

Hydraulics

COMFORT, SAFETY AND FUNCTIONALITY. FINALLY TOGIES COMMANDS AND CONTROLS Both models feature two modes of movement: first gear with reduced speed and high pushing force as well as second rpm at higher transmission speed. Everything is controlled by a convenient button above the backfill blade lever. Movement can be controlled using the feed lever and integrated folding pedals that increase space for the operator after closing and prevent accidental usage. The footboard flushing with the door ensures stepless exit from the cab while facilitating ground cleaning operations. It has been designed to be easily removed in order to perform exceptional maintenance. SCHRIFTTRAVEL In case of simultaneous control of services and movement, the hydraulic system uses variable displacement pumps simultaneously safeguards fluidity of movements and straight travel of the machine. AUTO-ZWEIGERUNG When the excavator needs more push power, automatic tempo gearboxes intervene thus reducing mobility ratio

THE IMPLEMENTATION OF BEING RELIABILITY. ECS: ONE CONCEPT, NUMEROUS POSSIBILITIES. Utilities AND SERVICES We listen to all your needs so that we can propose the best possible machine solution for you. We regard our products not only as a simple machine but also as the best opportunity for our customers. Services offered include among other services: Tailor-made paint Various track types Auxiliary line hooks adapted according to type and quantity Additional equipment The many available configurations allow you to make an optimal choice in terms of work to be done.
– Precise location of the machine on the Internet
Anti-theft with alarm and message by SMS/email High water temperature or low engine oil pressure alarm with notification by SMS/email Time monitoring with alarm due for service

OPTIONALS. The wide range of equipment specially designed for Eurocomach mini excavators ensures the most suitable use of the machine and maximizes performance. A complete offering of optional fittings provides best performances. Hydraulic system for chopper with additional pump (19 lt/min) auxiliary hydraulic system port with proportional electro-hydraulic control on the joystick Tailor made paint finish.

Dimensions and weight

The extremely compact dimensions make the 15 SR (reduced rear turning range) and 18 ZT (zero tail with enlarged carriage) your best allies for all your work needs both indoors and outdoors. The undercarriage and blade can be widened from 990 mm to 1300 mm

ensuring greater stability and therefore complete operating mobility.

Other features

The ergonomic driver's seat includes servo-assisted controls, wrist rests and movement lever with closing pedals. USB RADIO The radio is equipped with a convenient USB port.

ALL CONTROLS AT YOUR SERVICE. With its generous interior dimensions, the cab offers some of the best interior spaces in its class. The large width of the access door makes it easy to enter and exit. The front windshield with assisted lift promotes maximum visibility due to its considerable breadth. The adjustable suspension seat combined with the floating cabin dampens vibrations and shocks appropriately and maximizes operator comfort. Plus, the cab version is equipped with a radio, glove compartment and battery charger. Auxiliary hydraulic system and tilting are controlled by convenient pedals with folding guard to prevent accidental intervention.

ALL CONTROLS ON YOUR SERVICE. VISIBILITY The special design of the body and protective structures give the operator a wide field of vision allowing easy control of the front tracked part.The large windshield together with the upper rear window lets the operator keep an eye on the entire working area while sitting comfortably.WORK LIGHTS A powerful light installed on the arm optimizes visibility even in low lighting.

Safety

FLEXIBILITY, COMPACTNESS, ERGONOMICS. The practical extra external ballast (optional) can further increase excellent operating stability when needed without compromising the overall size of the machine. EFFICIENCY AND CONSUMPTION The heart of the excavators is the efficient YANMAR 3TNV70 - Stage 5 engine designed and built to optimize performance and reduce fuel consumption. Long intervals between programmed maintenance help achieve economy, reducing costs and downtime. SECURITY Machine safety means operator peace of mind. Sensors monitor manipulator position prevent accidental control of the machine. The excavator start system does not allow ignition during operation of commands. Safety belts, cab structure and rollbar with FOPS Level I and TOPS certificate provide all safety in the cabin in case of an accident. R 730 mm +80 kg OPTIONAL COUNTERWEIGHT

Tables

SAFETY
Machine blocking device during exit/access to the driver's seat	•	•
Engine ignition device only with the left console lowered	•	•
Anti-slip climbing plate	•	•
Climbing and descending handles	•	•
Emergency bar	•	•
Rearview mirror kit	•	•
Anti-drift safety valve on the first arm	second arm and backfill blade"	O	O
Pressure accumulator that allows the arm to be lowered in the event of an engine failure	•	•
HYDRAULIC SYSTEM
Open circuit hydraulic system with variable capacity pump	•	•
ISO hydraulic servo-control	•	•
Hydraulic oil intake filter	•	•
Rotation parking brake	•	•
Motion parking brake	•	•
Two speed motion system	•	•
Single and double effect hydraulic system	•	•
Hydraulic setup for calliper rotor (with switches on bucket cylinder)	o	o
Hydraulic setup for chopper (with additional pump)	O	O
AUX 2: Hydraulic setup for calliper rotor with pedal control (excludes tilting operation)	O	o
AUX 2: System setup for calliper rotor with proportional electro-hydraulic control on the Right joystick	O	O
ELECTRICAL SYSTEM
Work lights on the lifting arm	•	•
Supplementary work lights on the lifting arm	O	o
Supplementary front canopy/cap lights	O	O
Supplementary rear canopy/cap lights	o	O
Rotating light	o	o
Battery disconnect switch	•	•
Watertight connectors (IP67)	•	•

Diesel engine	3 cylinders	displacement 854 cc	watercooled"	•	•
Electric preheater	•	•
Dry air filter with discharge valve and filter clogged indicator	•	•
Double cartridge air filter	•	•
Cartridge engine oil filter	•	•
Cartridge fuel filter	•	•
Fuel filter with transparent water separation container	•	•
Fuel tank discharge	•	•
Auxiliary liquid refrigerant expansion tank	•	•
CANOPY
4 upright rollbar ROPS - TOPS - FOPS (Level I)	•	•
Adjustable mechanical suspension seat	O	O
Adjustable pneumatic suspension seat	o	O
Safety Belt	•	•
Wrist supports	•	•
Foot supports	•	•
Closable motion petals	•	•
Comfort rubber foot rest	•	•
Drivers seat platform assembled on 4 vibration damping elastic supports	•	•
Indicator light for hydraulic filter and engine air intake filter clog	•	•
Water temperature and fuel level indicators	•	•
Hour counter	•	•
High water temperature alarm	•	•
Warning buzzer	•	•
Single pole 12 volt power supply outlet	•	•
CAB
Cab ROPS - TOPS - FOPS (Level I)	O	O
Adjustable seat	•	•
Adjustable mechanical suspension seat	O	O
Adjustable pneumatic suspension seat		o
Safety Belt	•	•
Wrist supports	•	•
Closable motion petals	•	•
Comfort rubber foot rest	•	•
Heating system with speed adjustment	•	•
Sliding right side window	•	•
Windshield with assisted opening system (gas springs)	•	•
Rolling sun blind	•	•
Courtesy light	•	•
Indicator light for hydraulic filter and engine air intake filter clog	•	•
Water temperature and fuel level indicators	•	•
Hour counter	•	•
High water temperature alarm	•	•
Warning buzzer	•	•
Radio AM/FM USB	O	O
Single pole 12 volt power supply outlet	•	•
Front windshield wipers with sprayer and speed control	•	•

Antitheft system	O	O
Geo-service system for locating and remote diagnostics	o
Second excavating arm 950 mm	•	/
Second excavating arm 1100 mm	O	/
Second excavating arm 1	150 mm"	/	•
Second excavating arm 1	350 mm"	/	O
Additional external counterweight	O	o
Colour customizations (RAL specific)	O	O
4 anchoring points for lifting	•	•
On-board visual fuel level indicator	•	•
Lifting cylinder protective casing	•	•

UNDERCARRIAGE
Variable track undercarriage	/	•
Backfill blade	•	•
Dozer blade cylinder protective casing	•	•
Motion engines casing	•	•
Rotating joint protective casing	•	•
Rubber tracks	•	•
Iron tracks	O	O
Rubber road pad for iron tracks	o	o
4 anchoring points for transport	•	•

A (m)	1.0	2.0	3.0	MAX
							MAX
2.0,,,"0,42 (0,42)	0,26 (0,23)",,,"0,31 (0,34)	0,14 (0,17)	2,90 m"
1.0,,,"0,44 (0,44)	0,25 (0,21)	0,24 (0,32)	0,15 (0,18)	0,22 (0,25)	0,12 (0,14)	3,20 m"
0,,,"0,54 (0,54)	0,24 (0,21)	0,24 (0,31)	0,15 (0,17)	0,24 (0,26)	0,12 (0,15)	3,08 m"
-1.0,"0,41 (0,41)	0,27 (0,27)	0,55 (0,55)	0,25 (0,21)",,,"0,38 (0,41)	0,09 (0,12)	2,47 m"

A (m) 2.0

1.0

2.0

3.0

MAX MAX

,,"0,42 (0,42)	0,26 (0,23)",,,"0,31 (0,34)	0,14 (0,17)	2,90 m"
1.0,,,"0,44 (0,44)	0,25 (0,21)	0,28 (0,28)	0,15 (0,18)	0,22 (0,25)	0,12 (0,14)	3,20 m"
0,,,"0,54 (0,54)	0,24 (0,21)	0,27 (0,27)	0,15 (0,17)	0,24 (0,26)	0,12 (0,15)	3,08 m"
-1.0,"0,41 (0,41)	0,27 (0,27)	0,55 (0,55)	0,25 (0,21)",,,"0,38 (0,41)	0,15 (0,19)	2,47 m"

A (m) 2.0		B (m)
1.0	2.0	3.0	MAX	MAX

,,"0,42 (0,42)	0,26 (0,22)",,,"0,30 (0,32)	0,14 (0,17)	3,07 m"
1.0,,,"0,43 (0,43)	0,24 (0,21)	0,28 (0,28)	0,15 (0,18)	0,20 (0,23)	0,12 (0,14)	3,35 m"
0,,,"0,54 (0,54)	0,23 (0,2)	0,27 (0,27)	0,14 (0,17)	0,22 (0,24)	0,12 (0,15)	3,24 m"
-1.0,"0,41 (0,41)	0,27 (0,27)	0,55 (0,55)	*0,24 (0,21)",,,"0,36 (0,39)	0,09 (0,12)	2,67 m"

A (m)	1.0		2.0		3.0		MAX
								MAX
2.0,,,"0,42 (0,42)	0,26 (0,22)",,,"0,30 (0,32)	0,14 (0,17)	3,07 m"
1.0,,,"0,43 (0,43)	0,24 (0,21)	0,24 (*0,31)	0,15 (0,18)	0,20 (0,23)	0,12 (0,14)	3,35 m"
0,,,"0,54 (0,54)	0,23 (0,2)	0,23 (*0,3)	0,14 (0,17)	0,22 (0,24)	0,12 (0,15)	3,24 m"
-1.0,"0,41 (0,41)	0,27 (0,27)	0,55 (0,55)	*0,24 (0,21)",,,"0,36 (0,39)	0,09 (0,12)	2,67 m"

A (m)	1.0	2.0		3.0		MAX
							MAX
2.0,,,"0,41 (0,41)	0,36 (0,24)	0,32 (3,76)	0,21 (0,24)	0,31 (0,34)	0,16 (0,19)	3,13 m"
1.0,,,"0,44 (0,44)	0,34 (0,22)	0,24 (3,96)	0,19 (0,22)	0,22 (0,25)	0,14 (0,16)	3,40 m"
0,,,"0,54 (0,54)	0,35 (0,23)	0,24 (4,09)	0,18 (3,74)	0,23 (0,26)	0,15 (0,17)	3,29 m"
-1.0,"0,41 (0,41)	0,41 (0,41)	0,55 (0,55)	0,35 (*0,47)",,,"0,38 (0,41)	0,18 (0,22)	2,74 m"

A (m)	B (m)
	1.0	2.0	3.0		MAX
						MAX
2.0,,,"0,4 (0,4)	0,34 (0,23)	0,37 (0,37)	0,19 (2,11)	0,31 (0,34)	0,18 (0,21)	3,35 m"
1.0,,,"0,43 (0,43)	0,33 (0,21)	0,3 (0,3)	0,18 (0,22)	0,22 (0,25)	0,15 (0,18)	3,60 m"
0,,,"0,25 (0,25)	0,34 (0,22)	0,29 (0,29)	0,17 (0,21)	0,23 (0,26)	0,16 (0,19)	3,50 m"
-1.0,"0,4 (0,4)	0,4 (0,4)	0,54 (0,54)	0,34 (*0,46)",,,"0,38 (0,41)	0,21 (0,24)	2,99 m"

A (m)	B (m)
	1.0	2.0	3.0		MAX
						MAX
2.0,,,"0,4 (0,4)	0,34 (0,23)	0,31 (3,74)	0,19 (0,22)	0,31 (0,34)	0,16 (0,19)	3,35 m"
1.0,,,"0,43 (0,43)	0,33 (0,21)	0,23 (3,94)	0,18 (0,21)	0,22 (0,25)	0,14 (0,16)	3,60 m"
0,,,"0,53 (0,53)	0,34 (0,22)	0,22 (4,07)	0,17 (3,72)	0,23 (0,26)	0,15 (0,17)	3,50 m"
-1.0,"0,4 (0,4)	*0,4 (0,4)	0,54 (0,54)	0,34 (*0,46)",,,"0,38 (0,41)	0,18 (0,22)	2,99 m"

A (m)	1.0	2.0	3.0	MAX
				MAX
2.0,,,"0,41 (0,41)	0,36 (0,24)	0,38 (0,38)	0,21 (2,13)	0,31 (0,34)	0,18 (0,21)	3,13 m"
1.0,,,"0,44 (0,44)	0,34 (0,22)	0,31 (0,31)	0,19 (0,24)	0,22 (0,25)	0,15 (0,18)	3,40 m"
0,,,"0,26 (0,26)	0,35 (0,23)	0,3 (0,3)	0,18 (0,22)	0,23 (0,26)	0,16 (0,19)	3,29 m"
-1.0,"0,41 (0,41)	0,41 (0,41)	0,55 (0,55)	0,35 (*0,47)",,,"0,38 (0,41)	0,21 (0,24)	2,74 m"
