301.6C Caterpillar excavator specs & dimensions (2007 - 2026)

Caterpillar 301.6C is a mini excavator manufactured since 2007, with a weight of 1.61 tons. It has a transport length of 3.69 mete…

Caterpillar 301.6C is a mini excavator manufactured since 2007, with a weight of 1.61 tons. It has a transport length of 3.69 meters, a transport width of 0.97 meters, and a transport height of 2.19 meters. The bucket width is 0.98 meters.

301.6C

Years of manufacture: 2007—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 301.6C Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.61 t

Transport length: 3.69 m

Transport width: 0.97 m

Transport height: 2.19 m

Bucket width: 0.98 m

Engine manuf.: Mitsubishi

Engine type: L3E

Engine power: 13.5 kW

Displacement: 0.95 l

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., track width, standard tyres, driver protection, max. reach horizontal, dredging depth, tear-out force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

301.6C Caterpillar Specification for Europe (EN)

Caterpillar 301.6C FAQ

When was the Caterpillar 301.6C manufactured?

The Caterpillar 301.6C was first produced in 2007.

How much does the Caterpillar 301.6C weigh?

The Caterpillar 301.6C weighs 1.61 tons.

What are the transport dimensions of the Caterpillar 301.6C mini excavator?

The Caterpillar 301.6C has a transport length of 3.69 meters, a transport width of 0.97 meters, and a transport height of 2.19 meters.

What is the bucket width of the Caterpillar 301.6C mini excavator?

The bucket width of the Caterpillar 301.6C mini excavator is 0.98 meters.

How much is a Caterpillar 301.6C Mini excavator (2007u20132025) worth?

The residual value of the Caterpillar 301.6C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Caterpillar 301.6C overview

Engine / Driveline and transmission

Automatic Engine Idle. Automatically
lowers engine rpm when not in use to save fuel and less environmental noise/emissions.
Standard equipment may vary. Consult your Caterpillar dealer for details.
Alternator Automatic engine idle Auto swing hold brake Auxiliary hydraulic circuit valve, control elements and on the go (hammer) lines to stick auxiliary line for quick coupler Battery, maintenance-free Boom cylinder guard hood Canopy, FOPS ISO 10262 (Level, and TOPS ISO 12117 Coat hook Control Pattern Changer Cup holder Dozer blade with float function Floor mat Gauges or indicators for fuel level, engine coolant temperature, hour meter, engine oil pressure, air cleaner, alternator and glow plugs, service interval Hydraulic oil cooler Linkage pin connections, low maintenance Mobile phone bracket and socket Rubber track, 230 mm (9 in) wide Seat, suspension, vinyl covered seat belt, 50 mm (2 in) Stock, standard storage box, lockable travel alarm Travel pedal Two speed travel (dozer lever mounted) Working light, cab attachment, adjustable 301.6C/301.8C Mini Hydraulic Excavators Specifications
Optional equipment may vary. Consult your Caterpillar dealer for details.
Biodegradable hydraulic oil Boom backlash valve Cab fully glazed with FOPS conforming to ISO 10262 (Stage I), TOPS according to ISO 12177, heater/defroster, interior light, windscreen wiper and washer Ecology drain valve for hydraulic tank Fan and sun visor installation Front screen guard for cab and canopy immobiliser system Mechanical quick coupler Mirrors for cabin and canopy Radio/CD player Radio attachment kit Seat, suspension, fabric cover Seat, high back linkage, fabric covered seat belt, 75 mm (3 in) Stick, long Tool set Two ways (auger) Auxiliary lines to the stick Work Tools 301.6C/301.8C Mini Hydraulic Excavator Specifications

Hydraulics

Downtime is kept to a minimum with easy access to convenient daily check points.
Front Linkage. Protected front articulation lines are routed across the boom and stick to reduce damage and downtime. Service access. A large, swing-out rear door allows access to major components and service points within the engine enclosure, including: air filter, engine oil check and fill, engine oil filter element, radiator reservoir tank, control and fill, Verticallymounted, spin-on fuel filter/water separator, windshield washer fluid tank sight gauge. A hydraulic oil vision blade makes fluid level checks quick and easy. S, O, SSM Valve. The S OS oil sampling valve enables an easy removal of hydraulic fluid for preventative maintenance.

Dimensions and weight

Weights	301.6C	301.8C
Operating weight with canopy,"1610 kg 3,549 lb	1680 kg 3,704 lb"
Operating weight with cab,"1720 kg 3,792 lb	1785 kg 3,936 lb"

	301.6C	301.8C
Operating weight with canopy	1610 kg	3	549 lb"	1680 kg	3	704 lb"
Operating weight with cab	1720 kg	3	792 lb"	1785 kg	3	936 lb"

Pump – gear (tandem)	19.8 L/min	5.23 gal/min
Pump – gear (single)	14.6 L/min	3.86 gal/min
Operating pressures – equipment	206 bar	2	988 psi"
Operating pressure – travel	206 bar	2	988 psi"
Operating pressure – swing	174 bar	2	524 psi"
Auxiliary circuits – Primary (174 bar/2	524 psi)"	34.4 L/min	9.09 gal/min
Auxiliary circuits – Secondary (174 bar/2	524 psi)"	14.6 L/min	3.86 gal/min
Digging force – Stick	standard"	9.9 kN	2	226 lbf"
Digging force – Stick	long"	8.8 kN	1	978 lbf"
Digging force – Bucket	15.4 kN	3	462 lbf"

Other features

Low Effort Controls. Ergonomic, low
effort checks offer greater operator comfort for increased productivity. Dozer lever mounted, two-speed travel control provides easy operation and increases foot space.
Line of Sight Instrumentation.
The operator has a clear view of the machine's monitoring system, making fuel level, water temperature and warning lights easy to see.
Optional Fan and Sun Visor.
Operator comfort can be further increased with the optional fan and sun visor package. Operator Station. The large, spacious cab offers superior legroom, air circulation as well as an expansive viewing area with flat glass throughout for easy and cost-effective replacement.
Suspension Seat and Wrist Supports.
A suspension seat is standard and coupled with adjustable wrist rests, helping to increase operator comfort and fatigue.

Tables

Cooling system	4 L	1.06 gal
Engine oil	4.1 L	1.08 gal
Fuel tank	22 L	5.8 gal
Hydraulic tank	24 L	6.3 gal
Hydraulic system	37 L	9.8 gal

	301.6C	301.8C
Width – Standard	980 mm	38.6 in	980 mm 38.6 in
Width – Extended			1340 mm 52.8 in
Height	225 mm	8.9 in	255 mm 10.0 in
Dig depth	230 mm	9.1 in	250 mm 9.8 in
Lift height	180 mm	7.1 in	195 mm 7.7 in

Bore	76 mm	3.0 in
Stroke	70 mm	2.8 in
Displacement	0.95 L	58.1 in3

Model	Mitsubishi L3E NA Diesel
Rated net power (ISO 9249)	13.5 kW 18.1 hp
Gross power	14 kW 19 hp

Canopy	83 dB(A)
Cab	83 dB(A)

Machine swing speed	10.5 rpm
Boom swing – left (without stop)	90º
Boom swing – left (with stop)	54º

Travel System
Travel speed – high	4.5 km/h	2.8 mph
Travel speed – low	2 km/h	1.24 mph
Max traction force – high speed	7 kN	1	574 lbf"
Max traction force – low speed	15 kN	3	372 lbf"
Gradeability (max)	30º

Standard Stick	Long Stick
1	1550 mm	5'1"""	1560 mm	5'1"""
2	3350 mm	11'	3460 mm	11'4"""
3	2360 mm	7'9"""	2480 mm	8'2"""
4	2080 mm	6'10"""	2320 mm	7'7"""
5	1620 mm	5'4"""	1810 mm	5'11"""
6	3610 mm	11'10"""	3800 mm	12'6"""
7	3700 mm	12'2"""	3890 mm	12'9"""
8	1090 mm	3'7"""	1090 mm	3'7"""
9	2190 mm	7'2"""	2190 mm	7'2"""
10	1365 mm	4'6"""	1365 mm	4'6"""
11	435 mm	1'5"""	435 mm	1'5"""
12	1575 mm	5'2"""	1575 mm	5'2"""
13	3695 mm	12'1"""	3695 mm	12'1"""
14	975 mm	3'2"""	975 mm	3'2"""
15	980 mm	3'3"""	980 mm	3'3"""

Lift Capacities at Ground Level	Over Front	Over Side	Over Front	Over Side
Lift point radius	2000 mm	6'7"""	2000 mm	6'7"""	3000 mm	9'10"""	3000 mm	9'10"""
Standard track
Blade down	787 kg*	1	735 lb*"	362 kg	798 lb	450 kg*	992 lb*	219 kg	483 lb
Blade up	515 kg	1	135 lb"	329 kg	725 lb	300 kg	661 lb	201 kg	443 lb
Extended track (301.8 only)
Blade down	782 kg*	1	724 lb*"	580 kg	1	278 lb"	445 kg*	981 lb*	334 kg	736 lb
Blade up	524 kg	1	155 lb"	536 kg	1	181 lb"	303 kg	668 lb	311 kg	686 lb

	Standard Undercarriage	301.8C Extended Undercarriage
Track and blade width,"980 mm 3'3""	1340 mm 4'5"""
Gauge width	750 mm	1110 mm 3'8"""
2'6"""
Shoe width	230 mm	230 mm
9""	9"""
