218 Cams excavator specs & dimensions (2004 - 2008)

Cams 218 is a mini excavator manufactured from 2004 to 2008, with a weight of 1.8 tons. It has a transport length of 2.575 meters,…

Cams 218 is a mini excavator manufactured from 2004 to 2008, with a weight of 1.8 tons. It has a transport length of 2.575 meters, a transport width of 1 meter, and a transport height of 2.21 meters. The bucket width is 0.4 meters, and the bucket capacity is 0.06 cubic meters. Special equipment includes a blade and rubber track.

Mini Excavators Cams 218

Technical specs - 218 Cams

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.8 t
Transport length
2.575 m
Transport width
1 m
Transport height
2.21 m
Bucket capacity
0.06 m³
Bucket width
0.4 m
Track width
990 mm
Standard tyres
230
Driver protection
Kb
Max. Reach horizontal
3.92 m
Dredging depth
2.35 m
Tear-out force
15 kN
Engine manuf.
Kubota
Engine type
D1005E
Engine power
14.7 kW
Displacement
3 l
Revolutions at max torque
2500 rpm
Emission level
IIIB

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Cams 218 FAQ

When was the Cams 218 manufactured?

The Cams 218 was manufactured from 2004 to 2008.

How much does the Cams 218 mini excavator weigh?

The Cams 218 mini excavator weighs 1.8 tons.

What are the transport dimensions of the Cams 218 mini excavator?

The Cams 218 mini excavator has a transport length of 2.58 meters, a transport width of 1 meter, and a transport height of 2.21 meters.

What are the undercarriage specifications of the Cams 218 mini excavator?

The Cams 218 mini excavator has standard tyres measuring 230 mm and a track width of 990 mm.

What are the dredging depth and maximum horizontal reach of the Cams 218 mini excavator?

The Cams 218 mini excavator has a dredging depth of 2.35 meters and a maximum horizontal reach of 3.92 meters.

What is the tear-out force of the Cams 218 mini excavator?

The Cams 218 mini excavator has a tear-out force of 15 kN.

What are the bucket specifications of the Cams 218 mini excavator?

The Cams 218 mini excavator has a bucket capacity of 0.06 cubic meters and a bucket width of 0.4 meters.

What operator safety and support features does the Cams 218 have?

The Cams 218 provides operator safety through a protective cabin.

How much is a Cams 218 Mini excavator (2004u20132008) worth?

The residual value of the Cams 218 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
