E55W Bobcat excavator specs & dimensions (2009 - 2015)

Bobcat E55W is a mini excavator manufactured from 2009 to 2015, with a weight of 5.55 tons. It has a transport length of 6.12 mete…

Bobcat E55W is a mini excavator manufactured from 2009 to 2015, with a weight of 5.55 tons. It has a transport length of 6.12 meters, a transport width of 1.92 meters, and a transport height of 2.85 meters. The machine features a tear-out force of 27 kN and a dredging depth of 3.495 meters. It is equipped with a blade as special equipment.

Visit Bobcat live at

E55W

Years of manufacture: 2009—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - E55W Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.55 t

Transport length: 6.12 m

Transport width: 1.92 m

Transport height: 2.85 m

Driver protection: Kb

Max. Reach horizontal: 6.17 m

Dredging depth: 3.495 m

Tear-out force: 27 kN

Model series: E

Engine manuf.: Yanmar

Engine type: 4TNV98E

Engine power: 40.8 kW

Displacement: 3.3 l

Revolutions at max torque: 1550 rpm

Max. torque: 206 Nm

No. of cylinders: 4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, track width, standard tyres, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Bobcat E55W FAQ

When was the Bobcat E55W manufactured?

The Bobcat E55W was manufactured from 2009 to 2015.

How much does the Bobcat E55W weigh?

The Bobcat E55W weighs 5.55 tons.

What are the transport dimensions of the Bobcat E55W mini excavator?

The Bobcat E55W has a transport length of 6.12 meters, a transport width of 1.92 meters, and a transport height of 2.85 meters.

What are the excavation performance specifications of the Bobcat E55W mini excavator?

The Bobcat E55W mini excavator has a dredging depth of 3.495 meters and a maximum horizontal reach of 6.17 meters.

What is the tear-out force of the Bobcat E55W mini excavator?

The Bobcat E55W mini excavator has a tear-out force of 27 kN.

What operator safety features does the Bobcat E55W have?

The Bobcat E55W has operator safety features in the form of a cabin.

How much is a Bobcat E55W Mini excavator (2009u20132015) worth?

The residual value of the Bobcat E55W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
