604 Atlas excavator specs & dimensions (1995 - 1999)

Model rating
8,00 / 10

Atlas 604 is a mini excavator manufactured from 1995 to 1999. It has a weight of 2.9 tons and a track width of 300 mm. The transpo…

Atlas 604 is a mini excavator manufactured from 1995 to 1999. It has a weight of 2.9 tons and a track width of 300 mm. The transport dimensions are 4.53 meters in length, 1.45 meters in width, and 2.45 meters in height. The bucket width is 0.3 meters with a capacity of 0.11 cubic meters. This model is equipped with a blade.

Mini Excavators Atlas 604

Visit Atlas live at

Technical specs - 604 Atlas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.9 t
Transport length
4.53 m
Transport width
1.45 m
Transport height
2.45 m
Bucket capacity
0.11 m³
Bucket width
0.3 m
Track width
300 mm
Driver protection
Kb
Max. Reach horizontal
4.94 m
Dredging depth
3.14 m
Tear-out force
13.4 kN
Engine manuf.
Perkins
Engine type
103-15
Engine power
19 kW
Revolutions at max torque
2500 rpm

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Atlas 604 FAQ

When was the Atlas 604 manufactured?

The Atlas 604 was manufactured from 1995 to 1999.

How much does the Atlas 604 mini excavator weigh?

The Atlas 604 mini excavator weighs 2.9 tons.

What are the transport dimensions of the Atlas 604 mini excavator?

The Atlas 604 mini excavator has a transport length of 4.53 meters, a transport width of 1.45 meters, and a transport height of 2.45 meters.

What is the undercarriage specification of the Atlas 604 mini excavator?

The Atlas 604 mini excavator has a track width of 300 mm.

What are the dredging depth and maximum horizontal reach of the Atlas 604 mini excavator?

The Atlas 604 mini excavator has a dredging depth of 3.14 meters and a maximum horizontal reach of 4.94 meters.

What is the tear-out force of the Atlas 604 mini excavator?

The Atlas 604 mini excavator has a tear-out force of 13.4 kN.

What are the bucket specifications of the Atlas 604 mini excavator?

The Atlas 604 mini excavator has a bucket capacity of 0.11 cubic meters and a bucket width of 0.3 meters.

What operator safety and support features does the Atlas 604 mini excavator have?

The Atlas 604 mini excavator has a cabin that provides driver protection.

How much is a Atlas 604 Mini excavator (1995u20131999) worth?

The residual value of the Atlas 604 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
