B 7 -6 CR Yanmar excavator specs & Dimensions (2016 - 2024)

Yanmar B 7-6 CR is a crawler excavator manufactured since 2016, with a weight of 8.2 tons. It features a track width of 450 mm, a …

Yanmar B 7-6 CR is a crawler excavator manufactured since 2016, with a weight of 8.2 tons. It features a track width of 450 mm, a transport length of 5.85 meters, a transport width of 2.27 meters, and a transport height of 2.68 meters. The machine has a tear-out force of 56.9 kN, a dredging depth of 4.45 meters, and a maximum horizontal reach of 5.54 meters. Special equipment includes air conditioning, a blade, a diesel particulate filter, an overload alert, and both hydraulic and mechanical quick hitches.

Crawler Excavators Yanmar B 7 -6 CR

Technical specs - B 7 -6 CR Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.2 t
Transport length
5.85 m
Transport width
2.27 m
Transport height
2.68 m
Undercarriage
SL
Track width
450 mm
Boom
SKA
Max. Reach horizontal
5.54 m
Dredging depth
4.45 m
Tear-out force
56.9 kN
Model series
B
Engine manuf.
Yanmar
Engine type
4TNV98C
Engine power
39.3 kW
Displacement
3.318 l
Max. torque
241 Nm

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Yanmar B 7 -6 CR FAQ

When was the Yanmar B 7 -6 CR manufactured?

The Yanmar B 7 -6 CR was manufactured from 2016 to 2024.

How much does the Yanmar B 7 -6 CR weigh?

The Yanmar B 7 -6 CR weighs 8.2 tons.

What are the transport dimensions of the Yanmar B 7 -6 CR crawler excavator?

The Yanmar B 7 -6 CR has a transport length of 5.85 meters, a transport width of 2.27 meters, and a transport height of 2.68 meters.

What are the undercarriage specifications of the Yanmar B 7 -6 CR?

The Yanmar B 7 -6 CR has a standard undercarriage with a track width of 450 mm.

What are the excavation performance specifications of the Yanmar B 7 -6 CR crawler excavator?

The Yanmar B 7 -6 CR crawler excavator has a dredging depth of 4.45 meters, a maximum horizontal reach of 5.54 meters, and features a lateral articulated boom.

What are the power ratings of the Yanmar B 7 -6 CR?

There is no power rating data available for the Yanmar B 7 -6 CR in the provided source data.

How much is a Yanmar B 7 -6 CR Crawler excavator (2016u20132024) worth?

The residual value of the Yanmar B 7 -6 CR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
