14504 Wacker Neuson excavator specs & Dimensions (2010 - 2015)

Wacker Neuson 14504 is a crawler excavator manufactured from 2010 to 2015, with a weight of 15 tons. It has a transport length of …

Wacker Neuson 14504 is a crawler excavator manufactured from 2010 to 2015, with a weight of 15 tons. It has a transport length of 7.72 meters, a transport width of 2.49 meters, and a transport height of 2.79 meters. The excavator is equipped with air conditioning, a blade, and an overload alert system.

Visit Wacker Neuson live at

14504

Years of manufacture: 2010—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 14504 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15 t

Transport length: 7.72 m

Transport width: 2.49 m

Transport height: 2.79 m

Bucket capacity: 0.8 m³

Boom: MB

Max. Reach horizontal: 8.8 m

Dredging depth: 5.5 m

Engine manuf.: Deutz

Engine type: TDC2012

Engine power: 74.9 kW

Displacement: 4.038 l

Revolutions at max torque: 2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, tear-out force, bucket width, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: Yes
Cabin adjustment: No
Overload alert: Yes
Material Handling Excavator: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Wacker Neuson 14504 FAQ

When was the Wacker Neuson 14504 manufactured?

The Wacker Neuson 14504 was manufactured from 2010 to 2015.

How much does the Wacker Neuson 14504 weigh?

The Wacker Neuson 14504 weighs 15 tons.

What are the transport dimensions of the Wacker Neuson 14504 crawler excavator?

The Wacker Neuson 14504 has a transport length of 7.72 meters, a transport width of 2.49 meters, and a transport height of 2.79 meters.

What are the excavation performance specifications of the Wacker Neuson 14504?

The Wacker Neuson 14504 has a dredging depth of 5.5 meters, a maximum horizontal reach of 8.8 meters, and features a monobloc boom.

What is the bucket capacity of the Wacker Neuson 14504?

The Wacker Neuson 14504 has a bucket capacity of 0.8 cubic meters.

How much is a Wacker Neuson 14504 Crawler excavator (2010u20132015) worth?

The residual value of the Wacker Neuson 14504 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
