JY623E TRXBUILD excavator specs & Dimensions (2017 - 2025)

TRXBUILD JY623E is a Crawler Excavator manufactured since 2017, with a weight of 23 tons. It features a track width of 600 mm, a t…

TRXBUILD JY623E is a Crawler Excavator manufactured since 2017, with a weight of 23 tons. It features a track width of 600 mm, a transport length of 9.845 meters, a transport width of 3 meters, and a transport height of 3.3 meters. The machine has a tear-out force of 146 kN, a dredging depth of 6.83 meters, and a maximum horizontal reach of 10.02 meters. The bucket capacity is 1 cubic meter.

Crawler Excavators TRXBUILD JY623E

Technical specs - JY623E TRXBUILD

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23 t
Transport length
9.85 m
Transport width
3 m
Transport height
3.3 m
Bucket capacity
1 m³
Track width
600 mm
Max. Reach horizontal
10.02 m
Dredging depth
6.83 m
Tear-out force
146 kN
Model series
JY
Engine manuf.
Cummins
Engine type
B5.9C
Engine power
133 kW

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

TRXBUILD JY623E FAQ

When was the TRXBUILD JY623E manufactured?

The TRXBUILD JY623E was first produced in 2017.

How much does the TRXBUILD JY623E weigh?

The TRXBUILD JY623E weighs 23 tons.

What are the transport dimensions of the TRXBUILD JY623E crawler excavator?

The TRXBUILD JY623E has a transport length of 9.85 meters, a transport width of 3 meters, and a transport height of 3.3 meters.

What is the track width of the TRXBUILD JY623E's undercarriage?

The TRXBUILD JY623E has a track width of 600 mm.

What are the excavation performance specifications of the TRXBUILD JY623E?

The TRXBUILD JY623E has a dredging depth of 6.83 meters and a maximum horizontal reach of 10.02 meters.

What is the tear-out force of the TRXBUILD JY623E?

The TRXBUILD JY623E has a tear-out force of 146 kN.

What is the bucket capacity of the TRXBUILD JY623E crawler excavator?

The TRXBUILD JY623E crawler excavator has a bucket capacity of 1 cubic meter.

How much is a TRXBUILD JY623E Crawler excavator (2017u20132025) worth?

The residual value of the TRXBUILD JY623E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
