HR 41 Terex-Schaeff excavator specs & Dimensions (1996 - 2003)

Terex-Schaeff HR 41 is a crawler excavator manufactured from 1996 to 2003, with a weight of 11 tons. It features a track width of …

Terex-Schaeff HR 41 is a crawler excavator manufactured from 1996 to 2003, with a weight of 11 tons. It features a track width of 560 mm, a transport length of 5.15 meters, a transport width of 2.5 meters, and a transport height of 4.25 meters. The excavator is equipped with air conditioning.

Crawler Excavators Terex-Schaeff HR 41

Technical specs - HR 41 Terex-Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11 t
Transport length
5.15 m
Transport width
2.5 m
Transport height
4.25 m
Bucket capacity
0.41 m³
Track width
560 mm
Boom
MB
Max. Reach horizontal
5.74 m
Dredging depth
4.405 m
Tear-out force
54.8 kN
Bucket width
0.9 m
Model series
HR
Engine manuf.
Deutz
Engine type
BF4M1012E
Engine power
58 kW
Displacement
3.2 l
Revolutions at max torque
2300 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Terex-Schaeff HR 41 FAQ

When was the Terex-Schaeff HR 41 manufactured?

The Terex-Schaeff HR 41 was manufactured from 1996 to 2003.

How much does the Terex-Schaeff HR 41 weigh?

The Terex-Schaeff HR 41 weighs 11 tons.

What are the transport dimensions of the Terex-Schaeff HR 41?

The Terex-Schaeff HR 41 has a transport length of 5.15 meters, a transport width of 2.5 meters, and a transport height of 4.25 meters.

What is the track width of the Terex-Schaeff HR 41's undercarriage?

The Terex-Schaeff HR 41 has a track width of 560 mm.

What are the excavation performance specifications of the Terex-Schaeff HR 41?

The Terex-Schaeff HR 41 has a dredging depth of 4.405 meters, a maximum horizontal reach of 5.74 meters, and is equipped with a monobloc boom.

What are the power ratings of the Terex-Schaeff HR 41?

The source data does not provide power rating information for the Terex-Schaeff HR 41.

What are the specifications of the primary work tool (bucket) on the Terex-Schaeff HR 41?

The primary work tool of the Terex-Schaeff HR 41 has a bucket capacity of 0.41 cubic meters and a bucket width of 0.9 meters.
