HR 32 Terex-Schaeff excavator specs & Dimensions (2001 - 2005)

Terex-Schaeff HR 32 is a Crawler Excavator manufactured from 2001 to 2005. It has a weight of 7.5 tons and a track width of 450 mm…

Terex-Schaeff HR 32 is a Crawler Excavator manufactured from 2001 to 2005. It has a weight of 7.5 tons and a track width of 450 mm. The transport dimensions are 4.16 meters in length, 2.33 meters in width, and 4.34 meters in height. The bucket capacity is 0.335 cubic meters, and it is equipped with an overload alert system.

Crawler Excavators Terex-Schaeff HR 32

Technical specs - HR 32 Terex-Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.5 t
Transport length
4.16 m
Transport width
2.33 m
Transport height
4.34 m
Bucket capacity
0.335 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
6.17 m
Dredging depth
4.25 m
Tear-out force
39.4 kN
Bucket width
0.8 m
Model series
HR
Engine manuf.
Deutz
Engine type
BF4M1012E
Engine power
53 kW
Displacement
3.2 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Terex-Schaeff HR 32 FAQ

When was the Terex-Schaeff HR 32 manufactured?

The Terex-Schaeff HR 32 was manufactured from 2001 to 2005.

How much does the Terex-Schaeff HR 32 weigh?

The Terex-Schaeff HR 32 weighs 7.5 tons.

What are the transport dimensions of the Terex-Schaeff HR 32?

The Terex-Schaeff HR 32 has a transport length of 4.16 meters, a transport width of 2.33 meters, and a transport height of 4.34 meters.

What is the track width of the Terex-Schaeff HR 32 crawler excavator?

The Terex-Schaeff HR 32 crawler excavator has a track width of 450 mm.

What are the excavation performance specifications of the Terex-Schaeff HR 32?

The Terex-Schaeff HR 32 has a dredging depth of 4.25 meters, a maximum horizontal reach of 6.17 meters, and is equipped with a monobloc boom.

What is the power rating of the Terex-Schaeff HR 32?

The source data does not provide a power rating for the Terex-Schaeff HR 32.

What are the specifications of the primary work tool on the Terex-Schaeff HR 32?

The primary work tool of the Terex-Schaeff HR 32 has a bucket capacity of 0.335 cubic meters and a bucket width of 0.8 meters.

How much is a Terex-Schaeff HR 32 Crawler excavator (2001u20132005) worth?

The residual value of the Terex-Schaeff HR 32 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
