SWE300LC Sinoway excavator specs & Dimensions (2018 - 2026)

Sinoway SWE300LC is a Crawler Excavator manufactured since 2018. It has a weight of 31.3 tons and a track width of 600 mm. The tra…

Sinoway SWE300LC is a Crawler Excavator manufactured since 2018. It has a weight of 31.3 tons and a track width of 600 mm. The transport dimensions are 10.58 meters in length, 3.18 meters in width, and 3.5 meters in height. The excavator features a tear-out force of 177 kN, a dredging depth of 7.3 meters, and a maximum horizontal reach of 10.635 meters. It is equipped with a bucket capacity of 1.4 cubic meters and includes special equipment such as air conditioning and cabin adjustment.

Crawler Excavators Sinoway SWE300LC
Crawler Excavators Sinoway SWE300LC
Crawler Excavators Sinoway SWE300LC
Crawler Excavators Sinoway SWE300LC

Technical specs - SWE300LC Sinoway

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
31.3 t
Transport length
10.58 m
Transport width
3.18 m
Transport height
3.5 m
Bucket capacity
1.4 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.635 m
Dredging depth
7.3 m
Tear-out force
177 kN
Model series
SWE
Engine manuf.
Cummins
Engine type
B8.3
Engine power
166 kW
Displacement
8.3 l
No. of cylinders
6

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
Yes
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Sinoway SWE300LC FAQ

When was the Sinoway SWE300LC manufactured?

The Sinoway SWE300LC was first produced in 2018.

How much does the Sinoway SWE300LC weigh?

The Sinoway SWE300LC weighs 31.3 tons.

What are the transport dimensions of the Sinoway SWE300LC?

The Sinoway SWE300LC has a transport length of 10.58 meters, a transport width of 3.18 meters, and a transport height of 3.5 meters.

What are the undercarriage specifications of the Sinoway SWE300LC?

The Sinoway SWE300LC has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Sinoway SWE300LC crawler excavator?

The Sinoway SWE300LC crawler excavator has a dredging depth of 7.3 meters, a maximum horizontal reach of 10.635 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Sinoway SWE300LC?

The Sinoway SWE300LC has a tear-out force of 177 kN.

What is the bucket capacity of the Sinoway SWE300LC excavator?

The Sinoway SWE300LC excavator has a bucket capacity of 1.4 cubic meters.

How much is a Sinoway SWE300LC Crawler excavator (2018u20132025) worth?

The residual value of the Sinoway SWE300LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
