SE215-9W3 Shantui excavator specs & Dimensions (2025 - 2026)

Weight: 21.9t – Transport length: 9.6m – Transport width: 2.98m – Transport height: 3.1m – Bucket capacity: 1.05m³ – Max. Reach ho…

Weight: 21.9t – Transport length: 9.6m – Transport width: 2.98m – Transport height: 3.1m – Bucket capacity: 1.05m³ – Max. Reach horizontal: 9.865m

Check out detailed specifications, information and technical data for Shantui SE215-9W3 excavator manufactured between 2025 - 2026. Get more in-depth insight with Shantui SE215-9W3 digger specifications. See information, like: Weight: 21.9t – Transport length: 9.6m – Transport width: 2.98m – Transport height: 3.1m – Bucket capacity: 1.05m³ – Max. Reach horizontal: 9.865m and more.

Crawler Excavators Shantui SE215-9W3

Technical specs - SE215-9W3 Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.9 t
Transport length
9.6 m
Transport width
2.98 m
Transport height
3.1 m
Bucket capacity
1.05 m³
Max. Reach horizontal
9.865 m
Dredging depth
6.49 m
Engine manuf.
N/A
Engine type
N/a
Engine power
140 kW
Emission level
China III

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, tear-out force, bucket width, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, tear-out force, bucket width, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No
