RH 6.5 O&K excavator specs & Dimensions (2000 - 2005)

Model rating
9,50 / 10

O&K RH 6.5 is a crawler excavator manufactured from 2000 to 2005, with a weight of 21.5 tons. It features a track width of 600 mm,…

O&K RH 6.5 is a crawler excavator manufactured from 2000 to 2005, with a weight of 21.5 tons. It features a track width of 600 mm, a transport length of 9.55 meters, a transport width of 2.98 meters, and a transport height of 2.95 meters. The machine has a tear-out force of 88 kN.

Crawler Excavators O&K RH 6.5

Technical specs - RH 6.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.5 t
Transport length
9.55 m
Transport width
2.98 m
Transport height
2.95 m
Bucket capacity
0.9 m³
Undercarriage
SL
Track width
600 mm
Max. Reach horizontal
11.6 m
Dredging depth
7.2 m
Tear-out force
88 kN
Bucket width
1.1 m
Model series
RH
Engine manuf.
Cummins
Engine type
6BTA5.9C
Engine power
113 kW
Displacement
5.9 l
Revolutions at max torque
1900 rpm

More technical details, like: bucket capacity min., bucket capacity max., boom, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K RH 6.5 FAQ

When was the O&K RH 6.5 manufactured?

The O&K RH 6.5 was manufactured from 2000 to 2005.

How much does the O&K RH 6.5 weigh?

The O&K RH 6.5 weighs 21.5 tons.

What are the transport dimensions of the O&K RH 6.5 crawler excavator?

The O&K RH 6.5 crawler excavator has a transport length of 9.55 meters, a transport width of 2.98 meters, and a transport height of 2.95 meters.

What are the undercarriage specifications of the O&K RH 6.5 crawler excavator?

The O&K RH 6.5 crawler excavator has a standard undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the O&K RH 6.5?

The O&K RH 6.5 has a dredging depth of 7.2 meters and a maximum horizontal reach of 11.6 meters.

What is the tear-out force of the O&K RH 6.5 crawler excavator?

The O&K RH 6.5 crawler excavator has a tear-out force of 88 kN.

What are the bucket specifications of the O&K RH 6.5 crawler excavator?

The O&K RH 6.5 crawler excavator has a bucket capacity of 0.9 cubic meters and a bucket width of 1.1 meters.
