928E Liugong excavator specs & Dimensions (2019 - 2025)

Liugong 928E is a Crawler Excavator manufactured since 2019, with a weight of 27.5 tons and a track width of 700 mm. It has a tran…

Liugong 928E is a Crawler Excavator manufactured since 2019, with a weight of 27.5 tons and a track width of 700 mm. It has a transport length of 10.21 meters, a transport width of 3.29 meters, and a transport height of 3.48 meters. The machine features a tear-out force of 165 kN, a dredging depth of 6.925 meters, and a maximum horizontal reach of 10.34 meters. The bucket capacity is 1.2 cubic meters, and it comes equipped with air conditioning.

Crawler Excavators Liugong 928E

Visit Liugong live at

Technical specs - 928E Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
27.5 t
Transport length
10.21 m
Transport width
3.29 m
Transport height
3.48 m
Bucket capacity
1.2 m³
Track width
700 mm
Boom
MB
Max. Reach horizontal
10.34 m
Dredging depth
6.925 m
Tear-out force
165 kN
Model series
E
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
129 kW
Displacement
6.7 l
Revolutions at max torque
2000 rpm
Max. torque
809/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
107x124 mm
Emission level
EU IV

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Liugong 928E FAQ

When was the Liugong 928E manufactured?

The Liugong 928E was first produced in 2019.

How much does the Liugong 928E weigh?

The Liugong 928E weighs 27.5 tons.

What are the transport dimensions of the Liugong 928E crawler excavator?

The Liugong 928E crawler excavator has a transport length of 10.21 meters, a transport width of 3.29 meters, and a transport height of 3.48 meters.

What is the track width of the Liugong 928E's undercarriage?

The Liugong 928E has a track width of 700 mm on its undercarriage.

What are the excavation performance specifications of the Liugong 928E crawler excavator?

The Liugong 928E crawler excavator has a dredging depth of 6.925 meters, a maximum horizontal reach of 10.34 meters, and features a monobloc boom.

What is the tear-out force of the Liugong 928E?

The Liugong 928E has a tear-out force of 165 kN.

What is the bucket capacity of the Liugong 928E crawler excavator?

The Liugong 928E crawler excavator has a bucket capacity of 1.2 cubic meters.

How much is a Liugong 928E Crawler excavator (2019u20132025) worth?

The residual value of the Liugong 928E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
