924E Liugong excavator specs & Dimensions (2019 - 2025)

Liugong 924E is a Crawler Excavator manufactured since 2019. It has a weight of 24.5 tons and a track width of 700 mm. The transpo…

Liugong 924E is a Crawler Excavator manufactured since 2019. It has a weight of 24.5 tons and a track width of 700 mm. The transport dimensions are 9.57 meters in length, 3.09 meters in width, and 3.14 meters in height. The excavator features a tear-out force of 140 kN, a dredging depth of 6.562 meters, and a maximum horizontal reach of 9.87 meters. It is equipped with a bucket capacity of 1 cubic meter and includes air conditioning as special equipment.

Crawler Excavators Liugong 924E

Visit Liugong live at

Technical specs - 924E Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
24.5 t
Transport length
9.57 m
Transport width
3.09 m
Transport height
3.14 m
Bucket capacity
1 m³
Track width
700 mm
Boom
MB
Max. Reach horizontal
9.87 m
Dredging depth
6.562 m
Tear-out force
140 kN
Model series
E
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
119 kW
Displacement
6.7 l
Revolutions at max torque
2100 rpm
Max. torque
800/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
107x124 mm
Emission level
EU IV

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Liugong 924E FAQ

When was the Liugong 924E manufactured?

The Liugong 924E was first produced in 2019.

How much does the Liugong 924E weigh?

The Liugong 924E weighs 24.5 tons.

What are the transport dimensions of the Liugong 924E crawler excavator?

The Liugong 924E has a transport length of 9.57 meters, a transport width of 3.09 meters, and a transport height of 3.14 meters.

What is the track width of the Liugong 924E crawler excavator?

The Liugong 924E crawler excavator has a track width of 700 mm.

What are the excavation performance specifications of the Liugong 924E crawler excavator?

The Liugong 924E crawler excavator has a dredging depth of 6.562 meters, a maximum horizontal reach of 9.87 meters, and features a monobloc boom.

What is the tear-out force of the Liugong 924E?

The Liugong 924E has a tear-out force of 140 kN. Note that tear-out force is a measure of force, not a power rating.

What is the bucket capacity of the Liugong 924E crawler excavator?

The bucket capacity of the Liugong 924E crawler excavator is 1 cubic meter.

How much is a Liugong 924E Crawler excavator (2019u20132025) worth?

The residual value of the Liugong 924E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
