HD400VII EXCEED Kato excavator specs & Dimensions (1990 - 2023)

Kato HD400VII EXCEED is a crawler excavator manufactured since 1990. It has a weight of 10 tons and a track width of 500 mm. The t…

Kato HD400VII EXCEED is a crawler excavator manufactured since 1990. It has a weight of 10 tons and a track width of 500 mm. The transport dimensions are 7 meters in length, 2 meters in width, and 2 meters in height. The dredging depth is 5 meters, with a maximum horizontal reach of 8 meters. The bucket width is 1 meter.

Crawler Excavators Kato HD400VII EXCEED

Technical specs - HD400VII EXCEED Kato

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.5 t
Transport length
7.13 m
Transport width
2.49 m
Transport height
2.69 m
Bucket capacity min.
0.22 m³
Bucket capacity max.
0.5 m³
Track width
500 mm
Boom
MB
Max. Reach horizontal
8.12 m
Dredging depth
5.62 m
Bucket width
1 m
Engine manuf.
Mitsubishi
Engine type
4D31T
Engine power
61.1 kW
Displacement
3.298 l
Revolutions at max torque
1700 rpm
Max. torque
298.3 Nm
No. of cylinders
4
Cylinder bore x stroke
100 x 105 mm

More technical details, like: bucket capacity, undercarriage, tear-out force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato HD400VII EXCEED FAQ

When was the Kato HD400VII EXCEED manufactured?

The Kato HD400VII EXCEED was manufactured from 1990 to 2023.

How much does the Kato HD400VII EXCEED weigh?

The Kato HD400VII EXCEED weighs 10.5 tons.

What are the transport dimensions of the Kato HD400VII EXCEED?

The Kato HD400VII EXCEED has a transport length of 7.13 meters, a transport width of 2.49 meters, and a transport height of 2.69 meters.

What is the track width of the Kato HD400VII EXCEED's undercarriage?

The Kato HD400VII EXCEED has a track width of 500 mm.

What are the excavation performance specifications of the Kato HD400VII EXCEED?

The Kato HD400VII EXCEED has a dredging depth of 5.62 meters, a maximum horizontal reach of 8.12 meters, and features a monobloc boom.

What are the specifications of the bucket on the Kato HD400VII EXCEED crawler excavator?

The Kato HD400VII EXCEED crawler excavator has a bucket with a maximum capacity of 0.5 mu00b3, a minimum capacity of 0.22 mu00b3, and a width of 1 meter.

How much is a Kato HD400VII EXCEED Crawler excavator (1990u20132023) worth?

The residual value of the Kato HD400VII EXCEED depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
