75D John Deere Construction excavator specs & Dimensions (2010 - 2021)

John Deere Construction 75D is a crawler excavator manufactured from 2010 to 2021. It has a weight of 8 tons and a track width of …

John Deere Construction 75D is a crawler excavator manufactured from 2010 to 2021. It has a weight of 8 tons and a track width of 600 mm. The transport dimensions are 6.37 meters in length, 2.47 meters in width, and 2.69 meters in height. The machine features a tear-out force of 55 kN, a dredging depth of 4.11 meters, and a maximum horizontal reach of 6.26 meters. Special equipment includes a blade and track adjustment.

Crawler Excavators John Deere Construction 75D

Technical specs - 75D John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8 t
Transport length
6.37 m
Transport width
2.47 m
Transport height
2.69 m
Track width
600 mm
Max. Reach horizontal
6.26 m
Dredging depth
4.11 m
Tear-out force
55 kN
Model series
D
Engine manuf.
Isuzu
Engine type
4LE2X
Engine power
40 kW
Displacement
2.2 l
No. of cylinders
4
Emission level
Stage III

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 75D FAQ

When was the John Deere Construction 75D manufactured?

The John Deere Construction 75D was manufactured from 2010 to 2021.

How much does the John Deere Construction 75D weigh?

The John Deere Construction 75D weighs 8 tons.

What are the transport dimensions of the John Deere Construction 75D crawler excavator?

The John Deere Construction 75D has a transport length of 6.37 meters, a transport width of 2.47 meters, and a transport height of 2.69 meters.

What is the track width of the John Deere Construction 75D crawler excavator?

The John Deere Construction 75D crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the John Deere Construction 75D?

The John Deere Construction 75D has a dredging depth of 4.11 meters and a maximum horizontal reach of 6.26 meters.

What is the tear-out force of the John Deere Construction 75D?

The John Deere Construction 75D has a tear-out force of 55 kN.
