70D John Deere Construction excavator specs & Dimensions (1987 - 2021)

John Deere Construction 70D is a Crawler Excavator manufactured from 1987 to 2021, with a weight of 6.36 t. It features a track wi…

John Deere Construction 70D is a Crawler Excavator manufactured from 1987 to 2021, with a weight of 6.36 t. It features a track width of 600 mm, a transport length of 6.08 m, a transport width of 2.35 m, and a transport height of 2.57 m. The machine has a tear-out force of 44 kN, a dredging depth of 4.6 m, and a maximum horizontal reach of 6.63 m. The bucket width is 0.65 m with a capacity of 0.24 m³. Special equipment includes a blade and track adjustment.

Crawler Excavators John Deere Construction 70D

Technical specs - 70D John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.36 t
Transport length
6.08 m
Transport width
2.35 m
Transport height
2.57 m
Bucket capacity
0.24 m³
Track width
600 mm
Max. Reach horizontal
6.63 m
Dredging depth
4.6 m
Tear-out force
44 kN
Bucket width
0.650 m
Model series
D
Engine manuf.
N/A
Engine type
N/A
Engine power
41 kW
Displacement
3.9 l
No. of cylinders
4

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 70D FAQ

When was the John Deere Construction 70D manufactured?

The John Deere Construction 70D was manufactured from 1987 to 2021.

How much does the John Deere Construction 70D weigh?

The John Deere Construction 70D weighs 6.36 tons.

What are the transport dimensions of the John Deere Construction 70D?

The John Deere Construction 70D has a transport length of 6.08 meters, a transport width of 2.35 meters, and a transport height of 2.57 meters.

What is the track width of the John Deere Construction 70D crawler excavator?

The John Deere Construction 70D crawler excavator has a track width of 600 mm.

What is the excavation performance of the John Deere Construction 70D?

The John Deere Construction 70D has a dredging depth of 4.6 meters and a maximum horizontal reach of 6.63 meters.

What are the power ratings of the John Deere Construction 70D?

There are no power rating data available for the John Deere Construction 70D in the provided information.

What are the bucket specifications of the John Deere Construction 70D crawler excavator?

The John Deere Construction 70D crawler excavator has a bucket capacity of 0.24 cubic meters and a bucket width of 0.65 meters.

How much is a John Deere Construction 70D Crawler excavator (1987u20132021) worth?

The residual value of the John Deere Construction 70D depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
