470G John Deere Construction excavator specs & Dimensions (2011 - 2022)

John Deere Construction 470G is a crawler excavator manufactured from 2011 to 2022. It has a weight of 49.4 tons and a track width…

John Deere Construction 470G is a crawler excavator manufactured from 2011 to 2022. It has a weight of 49.4 tons and a track width of 900 mm. The transport dimensions are 12.1 meters in length, 3.79 meters in width, and 3.6 meters in height. The machine features a tear-out force of 285 kN, a dredging depth of 7.29 meters, and a maximum horizontal reach of 11.18 meters. Special equipment includes a blade and track adjustment.

Crawler Excavators John Deere Construction 470G

Technical specs - 470G John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
49.4 t
Transport length
12.1 m
Transport width
3.79 m
Transport height
3.6 m
Track width
900 mm
Max. Reach horizontal
11.18 m
Dredging depth
7.29 m
Tear-out force
285 kN
Model series
G
Engine manuf.
Isuzu
Engine type
6UZ1-iT4
Engine power
270 kW
Displacement
9.8 l
No. of cylinders
6

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

John Deere Construction 470G FAQ

When was the John Deere Construction 470G manufactured?

The John Deere Construction 470G was manufactured from 2011 to 2022.

How much does the John Deere Construction 470G weigh?

The John Deere Construction 470G weighs 49.4 tons.

What are the transport dimensions of the John Deere Construction 470G?

The John Deere Construction 470G has a transport length of 12.1 meters, a transport width of 3.79 meters, and a transport height of 3.6 meters.

What is the track width of the John Deere Construction 470G's undercarriage?

The John Deere Construction 470G has a track width of 900 mm.

What are the excavation performance specifications of the John Deere Construction 470G?

The John Deere Construction 470G has a dredging depth of 7.29 meters and a maximum horizontal reach of 11.18 meters.

What is the tear-out force of the John Deere Construction 470G?

The John Deere Construction 470G has a tear-out force of 285 kN.
