200G John Deere Construction excavator specs & Dimensions (2021 - 2026)

John Deere Construction 200G is a Crawler Excavator manufactured since 2021. It has a weight of 20.788 tons and a track width of 8…

John Deere Construction 200G is a Crawler Excavator manufactured since 2021. It has a weight of 20.788 tons and a track width of 800 mm. The transport dimensions are 9.04 meters in length, 3 meters in width, and 3.39 meters in height. The machine features a tear-out force of 95.1 kN, a dredging depth of 7.07 meters, and a maximum horizontal reach of 9.94 meters. The bucket capacity ranges from 0.42 m³ to 1.02 m³. Special equipment includes air conditioning, a blade, a diesel particulate filter, and track adjustment.

Crawler Excavators John Deere Construction 200G

Technical specs - 200G John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.788 t
Transport length
9.04 m
Transport width
3 m
Transport height
3.39 m
Bucket capacity min.
0.42 m³
Bucket capacity max.
1.02 m³
Track width
800 mm
Max. Reach horizontal
9.94 m
Dredging depth
7.07 m
Tear-out force
95.1 kN
Model series
G
Engine manuf.
John Deere
Engine type
PSS 4.5 L
Engine power
108 kW
Displacement
4.5 l
Revolutions at max torque
1400 rpm
Max. torque
614 Nm
No. of cylinders
4
Emission level
Tier 4/Stage IV

More technical details, like: bucket capacity, undercarriage, boom, bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 200G FAQ

When was the John Deere Construction 200G manufactured?

The John Deere Construction 200G was first produced in 2021.

How much does the John Deere Construction 200G weigh?

The John Deere Construction 200G weighs 20.79 tons.

What are the transport dimensions of the John Deere Construction 200G crawler excavator?

The John Deere Construction 200G has a transport length of 9.04 meters, a transport width of 3 meters, and a transport height of 3.39 meters.

What is the track width of the John Deere Construction 200G crawler excavator?

The John Deere Construction 200G crawler excavator has a track width of 800 mm.

What is the excavation performance of the John Deere Construction 200G?

The John Deere Construction 200G has a dredging depth of 7.07 meters and a maximum horizontal reach of 9.94 meters.

What is the tear-out force of the John Deere Construction 200G?

The John Deere Construction 200G has a tear-out force of 95.1 kN.

What are the bucket capacity specifications of the John Deere Construction 200G?

The John Deere Construction 200G has a bucket capacity ranging from 0.42 to 1.02 cubic meters.
