160G LC John Deere Construction excavator specs & Dimensions (2017 - 2026)

John Deere Construction 160G LC is a Crawler Excavator manufactured since 2017. It has a weight of 17.95 tons and a track width of…

John Deere Construction 160G LC is a Crawler Excavator manufactured since 2017. It has a weight of 17.95 tons and a track width of 700 mm. The transport dimensions are 8.65 meters in length, 2.69 meters in width, and 3.11 meters in height. The machine features a tear-out force of 119 kN, a dredging depth of 5.98 meters, and a maximum horizontal reach of 9.16 meters. It is equipped with air conditioning.

Crawler Excavators John Deere Construction 160G LC

Technical specs - 160G LC John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.95 t
Transport length
8.65 m
Transport width
2.69 m
Transport height
3.11 m
Undercarriage
LC
Track width
700 mm
Boom
MB
Max. Reach horizontal
9.16 m
Dredging depth
5.98 m
Tear-out force
119 kN
Model series
G
Engine manuf.
John Deere
Engine type
PowerTech PWS 4.5L
Engine power
90 kW
Displacement
4.5 l
Revolutions at max torque
2200 rpm
No. of cylinders
4
Emission level
Tier 4f/EU IV

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 160G LC FAQ

When was the John Deere Construction 160G LC manufactured?

The John Deere Construction 160G LC was first produced in 2017.

How much does the John Deere Construction 160G LC weigh?

The John Deere Construction 160G LC weighs 17.95 tons.

What are the transport dimensions of the John Deere Construction 160G LC?

The John Deere Construction 160G LC has a transport length of 8.65 meters, a transport width of 2.69 meters, and a transport height of 3.11 meters.

What are the undercarriage specifications of the John Deere Construction 160G LC?

The John Deere Construction 160G LC has a long undercarriage with a track width of 700 mm.

What are the excavation performance specifications of the John Deere Construction 160G LC?

The John Deere Construction 160G LC has a dredging depth of 5.98 meters, a maximum horizontal reach of 9.16 meters, and features a monobloc boom.

What are the power ratings of the John Deere Construction 160G LC?

The available data does not provide power ratings for the John Deere Construction 160G LC.

How much is a John Deere Construction 160G LC Crawler excavator (2017u20132025) worth?

The residual value of the John Deere Construction 160G LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
