HMK 230 LC Hidromek excavator specs & Dimensions (2019 - 2021)

Hidromek HMK 230 LC is a Crawler Excavator manufactured from 2020 to 2022. It has a weight of 23.65 tons and a track width of 600 …

Hidromek HMK 230 LC is a Crawler Excavator manufactured from 2020 to 2022. It has a weight of 23.65 tons and a track width of 600 mm. The transport dimensions are 9.68 meters in length, 2.99 meters in width, and 3.12 meters in height. The machine features a tear-out force of 154.9 kN, a dredging depth of 6.73 meters, and a maximum horizontal reach of 9.81 meters. The bucket width is 1.29 meters with a capacity of 1.1 cubic meters. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, hydraulic and mechanical quick hitches, and track adjustment.

Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC
Crawler Excavators Hidromek HMK 230 LC

Visit Hidromek live at

Technical specs - HMK 230 LC Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.65 t
Transport length
9.68 m
Transport width
2.99 m
Transport height
3.12 m
Bucket capacity
1.1 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.81 m
Dredging depth
6.73 m
Tear-out force
154.9 kN
Bucket width
1.29 m
Model series
HMK
Engine manuf.
Isuzu
Engine type
AR-4HK1X
Engine power
128 kW
Displacement
5.193 l
Revolutions at max torque
1600 rpm
Max. torque
670 Nm
No. of cylinders
4
Cylinder bore x stroke
115x125 mm
Emission level
Tier 4/EU IV

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Hidromek HMK 230 LC FAQ

When was the Hidromek HMK 230 LC manufactured?

The Hidromek HMK 230 LC was manufactured from 2019 to 2021.

How much does the Hidromek HMK 230 LC weigh?

The Hidromek HMK 230 LC weighs 23.65 tons.

What are the transport dimensions of the Hidromek HMK 230 LC?

The Hidromek HMK 230 LC has a transport length of 9.68 meters, a transport width of 2.99 meters, and a transport height of 3.12 meters.

What are the undercarriage specifications of the Hidromek HMK 230 LC?

The Hidromek HMK 230 LC has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Hidromek HMK 230 LC?

The Hidromek HMK 230 LC has a dredging depth of 6.73 meters, a maximum horizontal reach of 9.81 meters, and features a monobloc boom.

What is the tear-out force of the Hidromek HMK 230 LC?

The Hidromek HMK 230 LC has a tear-out force of 154.9 kN.

What are the specifications of the primary work tool on the Hidromek HMK 230 LC?

The primary work tool of the Hidromek HMK 230 LC has a bucket capacity of 1.1 cubic meters and a bucket width of 1.29 meters.

How much is a Hidromek HMK 230 LC Crawler excavator (2019u20132021) worth?

The residual value of the Hidromek HMK 230 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
