DX245DM-7 Develon excavator specs & Dimensions (2023 - 2026)

Weight: 30.7t – Transport length: 11.46m – Transport width: 2.54m – Transport height: 3.15m – Undercarriage: LCV – Track width: 55…

Weight: 30.7t – Transport length: 11.46m – Transport width: 2.54m – Transport height: 3.15m – Undercarriage: LCV – Track width: 550mm

Check out detailed specifications, information and technical data for Develon DX245DM-7 excavator manufactured between 2023 - 2026. Get more in-depth insight with Develon DX245DM-7 digger specifications. See information, like: Weight: 30.7t – Transport length: 11.46m – Transport width: 2.54m – Transport height: 3.15m – Undercarriage: LCV – Track width: 550mm and more.

Crawler Excavators Develon DX245DM-7

Visit Develon live at

Technical specs - DX245DM-7 Develon

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
30.7 t
Transport length
11.46 m
Transport width
2.54 m
Transport height
3.15 m
Undercarriage
LCV
Track width
550 mm
Boom
MB
Max. Reach horizontal
18.031 m
Model series
DX
Engine manuf.
Develon
Engine type
DL06V
Engine power
129 kW
Dimension lxwxh
1094x847x948 mm
Displacement
5.89 l
Revolutions at max torque
1800 rpm
Max. torque
804/1400 Nm
No. of cylinders
6
Cylinder bore x stroke
100x125 mm
Emission level
Stage V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., dredging depth, tear-out force, bucket width are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Develon DX245DM-7 FAQ

When was the Develon DX245DM-7 manufactured?

The Develon DX245DM-7 was first produced in 2023.

How much does the Develon DX245DM-7 weigh?

The Develon DX245DM-7 weighs 30.7 tons.

What are the transport dimensions of the Develon DX245DM-7 crawler excavator?

The Develon DX245DM-7 has a transport length of 11.46 meters, a transport width of 2.54 meters, and a transport height of 3.15 meters.

What are the undercarriage specifications of the Develon DX245DM-7?

The Develon DX245DM-7 has a long undercarriage that is hydraulically extendable and features a track width of 550 mm.

What is the excavation performance of the Develon DX245DM-7?

The Develon DX245DM-7 has a maximum horizontal reach of 18.031 meters and features a monobloc boom.

What is the bucket width of the Develon DX245DM-7?

The bucket width of the Develon DX245DM-7 is not available.

How much is a Develon DX245DM-7 Crawler excavator (2023u20132025) worth?

The residual value of the Develon DX245DM-7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
