ZG3255LC-9 Changlin excavator specs & Dimensions (2017 - 2026)

Changlin ZG3255LC-9 is a crawler excavator manufactured since 2017. It has a weight of 25 tons and a track width of 600 mm. The tr…

Changlin ZG3255LC-9 is a crawler excavator manufactured since 2017. It has a weight of 25 tons and a track width of 600 mm. The transport dimensions are 9.84 meters in length, 3.18 meters in width, and 3.18 meters in height. The machine offers a tear-out force of 159 kN, a dredging depth of 6.995 meters, and a maximum horizontal reach of 10.258 meters. The bucket capacity is 1.2 cubic meters.

Crawler Excavators Changlin ZG3255LC-9

Technical specs - ZG3255LC-9 Changlin

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25 t
Transport length
9.84 m
Transport width
3.18 m
Transport height
3.18 m
Bucket capacity
1.2 m³
Undercarriage
LC
Track width
600 mm
Max. Reach horizontal
10.258 m
Dredging depth
6.995 m
Tear-out force
159 kN
Model series
ZG
Engine manuf.
Cummins
Engine type
6BTAA5.9-C178
Engine power
133 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, bucket width, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Changlin ZG3255LC-9 FAQ

When was the Changlin ZG3255LC-9 manufactured?

The Changlin ZG3255LC-9 was first produced in 2017.

How much does the Changlin ZG3255LC-9 weigh?

The Changlin ZG3255LC-9 weighs 25 tons.

What are the transport dimensions of the Changlin ZG3255LC-9 crawler excavator?

The Changlin ZG3255LC-9 crawler excavator has a transport length of 9.84 meters, a transport width of 3.18 meters, and a transport height of 3.18 meters.

What are the undercarriage specifications of the Changlin ZG3255LC-9?

The Changlin ZG3255LC-9 has a long undercarriage and a track width of 600 mm.

What are the dredging depth and maximum horizontal reach of the Changlin ZG3255LC-9?

The Changlin ZG3255LC-9 has a dredging depth of 6.995 meters and a maximum horizontal reach of 10.258 meters.

What power ratings are available for the Changlin ZG3255LC-9?

The available data for the Changlin ZG3255LC-9 does not include power ratings. However, it has a tear-out force of 159 kN.

What is the bucket capacity of the Changlin ZG3255LC-9 excavator?

The bucket capacity of the Changlin ZG3255LC-9 is 1.2 cubic meters.

How much is a Changlin ZG3255LC-9 Crawler excavator (2017u20132025) worth?

The residual value of the Changlin ZG3255LC-9 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
