323 Caterpillar excavator specs & Dimensions (2017 - 2020)

Caterpillar 323 is a Crawler Excavator manufactured from 2017 to 2020, with a weight of 25.1 tons. It features a track width of 79…

Caterpillar 323 is a Crawler Excavator manufactured from 2017 to 2020, with a weight of 25.1 tons. It features a track width of 790 mm, a transport length of 9.53 meters, a transport width of 3.17 meters, and a transport height of 2.96 meters. The machine has a tear-out force of 140 kN, a dredging depth of 6.73 meters, a maximum horizontal reach of 9.87 meters, and a bucket capacity of 1.3 cubic meters.

323

Years of manufacture: 2017—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 323 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 25.1 t

Transport length: 9.53 m

Transport width: 3.17 m

Transport height: 2.96 m

Bucket capacity: 1.3 m³

Undercarriage: LC

Track width: 790 mm

Boom: MB

Max. Reach horizontal: 9.87 m

Dredging depth: 6.73 m

Tear-out force: 140 kN

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 121 kW

Displacement: 7 l

Cylinder bore x stroke: 105x135 mm

Emission level: U.S. EPA Tier 4 Final / EU IV

More technical details, like: bucket capacity min., bucket capacity max., bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: No
Cabin adjustment: No
Overload alert: No
Material Handling Excavator: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 323 FAQ

When was the Caterpillar 323 manufactured?

The Caterpillar 323 was manufactured from 2017 to 2020.

How much does the Caterpillar 323 weigh?

The Caterpillar 323 weighs 25.1 tons.

What are the transport dimensions of the Caterpillar 323?

The Caterpillar 323 has a transport length of 9.53 meters, a transport width of 3.17 meters, and a transport height of 2.96 meters.

What are the undercarriage specifications of the Caterpillar 323?

The Caterpillar 323 has a long undercarriage and a track width of 790 mm.

What are the excavation performance specifications of the Caterpillar 323?

The Caterpillar 323 has a dredging depth of 6.73 meters, a maximum horizontal reach of 9.87 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Caterpillar 323?

The Caterpillar 323 has a tear-out force of 140 kN.

What is the bucket capacity of the Caterpillar 323 excavator?

The Caterpillar 323 excavator has a bucket capacity of 1.3 cubic meters.

How much is a Caterpillar 323 Crawler excavator (2017u20132020) worth?

The residual value of the Caterpillar 323 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Caterpillar 323 overview

Caterpillar 323 features overview

Next generation excavators

The new line of Cat Excavators was designed with a new approach to equipment families that gives you: MORE MODEL OPTIONS MORE STANDARD TECHNOLOGIES MORE PRICE POINTS Ready to help you make your business stronger, Cat Excavators give you new ways to get the most work done at the lowest cost—so you put more money in your pocket.

New Cab Takes the Hard Out of Work

Sites where excavators typically work are rugged and challenging. That’s why it’s important that the 323 cab protects the operator as much as possible from the fatigue, stresses, sounds and temperatures of the job.

With cat attachments

You can easily expand the performance of your machine by utilizing any of the variety of Cat Attachments. Each Cat Attachment is designed to fit the weight and horsepower of Cat Excavators for improved performance, safety and stability.

Engine

Reduce fuel consumption up to 20%

A precise combination of lower engine speed and a large hydraulic pump delivers top performance while burning less fuel.

New Smart Mode

The new Smart Mode (one of three power mode settings) automatically adjusts engine and hydraulic power for the highest fuel efficiency—less power for tasks such as swinging and more power for digging.

Safety Features

Daily maintenance checks can be performed with 100% of the points accessible from ground level, making maintenance faster, easier and safer. Checkpoints include the engine oil dipstick, fuel water separator, fuel tank water and sediment drains, and cooling system coolant level check.

Cab

New Seat and Joystick Console Reduce Fatigue

Comfort and efficiency of movement keep operators productive and alert all shift long. The new standard seat is wide and adjustable for operators of virtually any size. The Deluxe cab package includes a heated air suspension seat; the Premium seat is both heated and cooled.

ISO-Certified ROPS Cab

The ISO-certified ROPS cab is sound-suppressed and sealed. The windows and lower front profile of the machine give outstanding visibility to the work area without the strain of constantly leaning forward.

All-Around Visibility

A standard rearview camera keeps operators aware of their surroundings at all times. An optional 360° Visibility feature is also available.

Equipment

Keyless Push Start

The 323 uses a keyless push-button engine start. This adds security for the machine by using Operator ID codes to limit and track machine access. Codes can be entered manually, via an optional Bluetooth key fob or smartphone app.

Keep Your Excavator Secure

Use your PIN code on the monitor, the optional Bluetooth key fob or your smartphone to enable the push-button starting feature.

Standard 2D E-Fence Technology

The standard 2D E-fence feature automatically stops excavator motion using boundaries you set in the monitor for the entire working envelope—above, below, sides and front. E-fence features protect equipment from damage and reduce fines related to zoning or underground utility damage. Automatic boundaries even help prevent operator fatigue by reducing over-swinging and over-digging.
