320GC Caterpillar excavator specs & Dimensions (2020 - 2026)

Caterpillar 320GC is a Crawler Excavator manufactured since 2020. It has a weight of 21.9 tons and a track width of 790 mm. The tr…

Caterpillar 320GC is a Crawler Excavator manufactured since 2020. It has a weight of 21.9 tons and a track width of 790 mm. The transport dimensions are 9.53 meters in length, 3.17 meters in width, and 2.96 meters in height. The machine offers a tear-out force of 129 kN, a dredging depth of 6.72 meters, and a maximum horizontal reach of 9.86 meters. The bucket capacity is 1.19 cubic meters.

Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC
Crawler Excavators Caterpillar 320GC

Technical specs - 320GC Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.9 t
Transport length
9.53 m
Transport width
3.17 m
Transport height
2.96 m
Bucket capacity
1.19 m³
Undercarriage
SL
Track width
790 mm
Boom
MB
Max. Reach horizontal
9.86 m
Dredging depth
6.72 m
Tear-out force
129 kN
Engine manuf.
Caterpillar
Engine type
C4.4 Acert
Engine power
90 kW
Displacement
4.4 l
Cylinder bore x stroke
105x127 mm
Emission level
EU V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 320GC FAQ

When was the Caterpillar 320GC manufactured?

The Caterpillar 320GC was first produced in 2020.

How much does the Caterpillar 320GC weigh?

The Caterpillar 320GC weighs 21.9 tons.

What are the transport dimensions of the Caterpillar 320GC?

The Caterpillar 320GC has a transport length of 9.53 meters, a transport width of 3.17 meters, and a transport height of 2.96 meters.

What are the undercarriage specifications of the Caterpillar 320GC?

The Caterpillar 320GC has a standard undercarriage with a track width of 790 mm.

What are the excavation performance specifications of the Caterpillar 320GC?

The Caterpillar 320GC has a dredging depth of 6.72 meters, a maximum horizontal reach of 9.86 meters, and features a monobloc boom.

What is the power rating of the Caterpillar 320GC?

There is no power rating information available for the Caterpillar 320GC in the provided data.

What is the bucket capacity of the Caterpillar 320GC?

The bucket capacity of the Caterpillar 320GC is 1.19 cubic meters.
