319D Caterpillar excavator specs & Dimensions (2010 - 2026)

Caterpillar 319D is a Crawler Excavator manufactured since 2010, with a weight of 20 tons. It features a track width of 600 mm, a …

Caterpillar 319D is a Crawler Excavator manufactured since 2010, with a weight of 20 tons. It features a track width of 600 mm, a transport length of 8.77 meters, a transport width of 2.8 meters, and a transport height of 3.08 meters. The dredging depth is 6.42 meters, and the maximum horizontal reach is 9.3 meters.

Crawler Excavators Caterpillar 319D

Technical specs - 319D Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20 t
Transport length
8.77 m
Transport width
2.8 m
Transport height
3.08 m
Track width
600 mm
Max. Reach horizontal
9.3 m
Dredging depth
6.42 m
Engine manuf.
Caterpillar
Engine type
C4.2 Acert
Engine power
93 kW
Displacement
4.25 l
No. of cylinders
4
Cylinder bore x stroke
102x130 mm

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 319D FAQ

When was the Caterpillar 319D manufactured?

The Caterpillar 319D was first produced in 2010.

How much does the Caterpillar 319D weigh?

The Caterpillar 319D weighs 20 tons.

What are the transport dimensions of the Caterpillar 319D?

The Caterpillar 319D has a transport length of 8.77 meters, a transport width of 2.8 meters, and a transport height of 3.08 meters.

What is the average fuel consumption of the Caterpillar 319D crawler excavator?

The Caterpillar 319D has an average fuel consumption of 13.1 liters per hour.

What is the track width of the Caterpillar 319D crawler excavator?

The Caterpillar 319D crawler excavator has a track width of 600 mm.

What is the excavation performance of the Caterpillar 319D?

The Caterpillar 319D has a dredging depth of 6.42 meters and a maximum horizontal reach of 9.3 meters.
