CX210D   Case excavator specs & Dimensions (2016 - 2021)

Case CX210D is a Crawler Excavator manufactured from 2016 to 2023, with a weight of 22.6 tons. It features a track width of 500 mm…

Case CX210D is a Crawler Excavator manufactured from 2016 to 2023, with a weight of 22.6 tons. It features a track width of 500 mm, a transport length of 9.54 meters, a transport width of 2.49 meters, and a transport height of 3.31 meters. The machine has a tear-out force of 103 kN, a dredging depth of 5.8 meters, and a maximum horizontal reach of 9.22 meters. The bucket width is 1.3 meters with a capacity of 1 cubic meter. Special equipment includes air conditioning, overload alert, and a hydraulic quick hitch.

Crawler Excavators Case CX210D
Crawler Excavators Case CX210D
Crawler Excavators Case CX210D
Crawler Excavators Case CX210D
Crawler Excavators Case CX210D
Crawler Excavators Case CX210D

Technical specs - CX210D   Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.6 t
Transport length
9.54 m
Transport width
2.49 m
Transport height
3.31 m
Bucket capacity
1 m³
Undercarriage
NLC
Track width
500 mm
Boom
VA
Max. Reach horizontal
9.22 m
Dredging depth
5.8 m
Tear-out force
103 kN
Bucket width
1.3 m
Model series
D
Engine manuf.
Isuzu
Engine type
AR 4HK1X
Engine power
119.3 kW
Displacement
5.2 l
Revolutions at max torque
1600 rpm
Max. torque
620 Nm
No. of cylinders
4
Emission level
Tier 4 f

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Case CX210D   FAQ

When was the Case CX210D manufactured?

The Case CX210D was manufactured from 2016 to 2021.

How much does the Case CX210D weigh?

The Case CX210D weighs 22.6 tons.

What are the transport dimensions of the Case CX210D crawler excavator?

The Case CX210D crawler excavator has a transport length of 9.54 meters, a transport width of 2.49 meters, and a transport height of 3.31 meters.

What are the undercarriage specifications of the Case CX210D?

The Case CX210D has a small undercarriage with a track width of 500 mm.

What are the excavation performance specifications of the Case CX210D?

The Case CX210D has an adjustable boom, a dredging depth of 5.8 meters, and a maximum horizontal reach of 9.22 meters.

What is the tear-out force of the Case CX210D?

The Case CX210D has a tear-out force of 103 kN.

What are the bucket specifications of the Case CX210D excavator?

The Case CX210D excavator has a bucket capacity of 1 cubic meter and a bucket width of 1.3 meters.

How much is a Case CX210D u00a0 Crawler excavator (2016u20132021) worth?

The residual value of the Case CX210D u00a0 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
