CX210C  Case excavator specs & Dimensions (2014 - 2017)

Case CX210C is a Crawler Excavator manufactured from 2014 to 2017. It has a weight of 21.8 tons and a track width of 500 mm. The t…

Case CX210C is a Crawler Excavator manufactured from 2014 to 2017. It has a weight of 21.8 tons and a track width of 500 mm. The transport dimensions are 9.57 meters in length, 2.49 meters in width, and 3.31 meters in height. The machine features a tear-out force of 142 kN, a dredging depth of 6.11 meters, and a maximum horizontal reach of 9.24 meters. The bucket capacity is 1 cubic meter. Special equipment includes an overload alert and a hydraulic quick hitch.

Crawler Excavators Case CX210C

Technical specs - CX210C  Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.8 t
Transport length
9.57 m
Transport width
2.49 m
Transport height
3.31 m
Bucket capacity
1 m³
Undercarriage
NLC
Track width
500 mm
Boom
MB
Max. Reach horizontal
9.24 m
Dredging depth
6.11 m
Tear-out force
142 kN
Model series
C
Engine manuf.
Isuzu
Engine type
AM 4 HK 1 X
Engine power
140 kW
Displacement
5.2 l
Revolutions at max torque
1800 rpm
Max. torque
642 Nm
No. of cylinders
4
Cylinder bore x stroke
115 x 125 mm
Emission level
Tier 4 f

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Case CX210C  FAQ

When was the Case CX210C manufactured?

The Case CX210C was manufactured from 2014 to 2017.

How much does the Case CX210C weigh?

The Case CX210C weighs 21.8 tons.

What are the transport dimensions of the Case CX210C crawler excavator?

The Case CX210C crawler excavator has a transport length of 9.57 meters, a transport width of 2.49 meters, and a transport height of 3.31 meters.

What are the undercarriage specifications of the Case CX210C?

The Case CX210C has a small undercarriage with a track width of 500 mm.

What are the excavation performance specifications of the Case CX210C?

The Case CX210C has a dredging depth of 6.11 meters, a maximum horizontal reach of 9.24 meters, and is equipped with a monobloc boom.

What are the power ratings of the Case CX210C?

The source data does not provide power rating information for the Case CX210C.

What is the bucket capacity of the Case CX210C?

The Case CX210C has a bucket capacity of 1 cubic meter.

How much is a Case CX210Cu00a0 Crawler excavator (2014u20132017) worth?

The residual value of the Case CX210Cu00a0 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
