CX145D SR Case excavator specs & Dimensions (2021 - 2026)

Case CX145D SR is a crawler excavator manufactured since 2021, with a weight of 15.2 tons. It features a track width of 600 mm, a …

Case CX145D SR is a crawler excavator manufactured since 2021, with a weight of 15.2 tons. It features a track width of 600 mm, a transport length of 7.46 meters, a transport width of 2.59 meters, and a transport height of 2.92 meters. The machine has a tear-out force of 90 kN, a dredging depth of 5.31 meters, and a maximum horizontal reach of 8.28 meters. Special equipment includes air conditioning and an overload alert system.

CX145D SR

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CX145D SR Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15.2 t

Transport length: 7.46 m

Transport width: 2.59 m

Transport height: 2.92 m

Track width: 600 mm

Boom: VA

Max. Reach horizontal: 8.28 m

Dredging depth: 5.31 m

Tear-out force: 90 kN

Model series: D

Engine manuf.: Isuzu

Engine type: AR-4JJ1X

Engine power: 76.4 kW

Displacement: 2.99 l

Revolutions at max torque: 1800 rpm

Max. torque: 349 Nm

No. of cylinders: 4

Cylinder bore x stroke: 95.4x104.9 mm

Emission level: EU V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: No
Cabin adjustment: No
Overload alert: Yes
Material Handling Excavator: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Case CX145D SR FAQ

When was the Case CX145D SR manufactured?

The Case CX145D SR was first produced in 2021.

How much does the Case CX145D SR weigh?

The Case CX145D SR weighs 15.2 tons.

What are the transport dimensions of the Case CX145D SR crawler excavator?

The Case CX145D SR crawler excavator has a transport length of 7.46 meters, a transport width of 2.59 meters, and a transport height of 2.92 meters.

What is the track width of the Case CX145D SR's undercarriage?

The Case CX145D SR has a track width of 600 mm.

What are the excavation performance specifications of the Case CX145D SR?

The Case CX145D SR has an adjustable boom, a dredging depth of 5.31 meters, and a maximum horizontal reach of 8.28 meters.

What is the tear-out force of the Case CX145D SR?

The Case CX145D SR has a tear-out force of 90 kN.

How much is a Case CX145D SR Crawler excavator (2021u20132025) worth?

The residual value of the Case CX145D SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
