CX 210 C Case excavator specs & Dimensions (2011 - 2014)

Model rating
1,00 / 10

Case CX 210 C is a Crawler Excavator manufactured from 2011 to 2014. It has a weight of 21.5 tons, a track width of 600 mm, a tran…

Case CX 210 C is a Crawler Excavator manufactured from 2011 to 2014. It has a weight of 21.5 tons, a track width of 600 mm, a transport length of 9.47 meters, a transport width of 2.99 meters, and a transport height of 3.09 meters. The machine features a tear-out force of 103 kN and comes equipped with air conditioning and an overload alert system.

Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C
Crawler Excavators Case CX 210 C

Technical specs - CX 210 C Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.5 t
Transport length
9.47 m
Transport width
2.99 m
Transport height
3.09 m
Bucket capacity
1.15 m³
Undercarriage
NLC
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.9 m
Dredging depth
6.65 m
Tear-out force
103 kN
Bucket width
1.3 m
Model series
C
Engine manuf.
Isuzu
Engine type
AM 4 HK 1 X
Engine power
119 kW
Displacement
5.2 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX 210 C FAQ

When was the Case CX 210 C manufactured?

The Case CX 210 C was manufactured from 2011 to 2014.

How much does the Case CX 210 C weigh?

The Case CX 210 C weighs 21.5 tons.

What are the transport dimensions of the Case CX 210 C crawler excavator?

The Case CX 210 C has a transport length of 9.47 meters, a transport width of 2.99 meters, and a transport height of 3.09 meters.

What are the undercarriage specifications of the Case CX 210 C?

The Case CX 210 C has a small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Case CX 210 C crawler excavator?

The Case CX 210 C has a dredging depth of 6.65 meters, a maximum horizontal reach of 9.9 meters, and features a monobloc boom.

What is the tear-out force of the Case CX 210 C?

The Case CX 210 C has a tear-out force of 103 kN.

What are the specifications of the primary work tool bucket on the Case CX 210 C?

The primary work tool bucket of the Case CX 210 C has a capacity of 1.15 cubic meters and a width of 1.3 meters.

How much is a Case CX 210 C Crawler excavator (2011u20132014) worth?

The residual value of the Case CX 210 C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
