9040 Case excavator specs & Dimensions (1990 - 2015)

Case 9040 is a Crawler Excavator manufactured from 1990 to 2015. It has a weight of 24.47 tons and a track width of 800 mm. The tr…

Case 9040 is a Crawler Excavator manufactured from 1990 to 2015. It has a weight of 24.47 tons and a track width of 800 mm. The transport dimensions are 9.88 meters in length, 3.38 meters in width, and 3.07 meters in height. The excavator features a tear-out force of 145 kN, a dredging depth of 7.39 meters, and a maximum horizontal reach of 10.64 meters. The bucket width is 1.37 meters, with a bucket capacity ranging from 0.57 m³ to 1.15 m³.

Crawler Excavators Case 9040

Technical specs - 9040 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
24.47 t
Transport length
9.88 m
Transport width
3.38 m
Transport height
3.07 m
Bucket capacity
1.15 m³
Bucket capacity min.
0.57 m³
Bucket capacity max.
1.15 m³
Undercarriage
HD
Track width
800 mm
Max. Reach horizontal
10.64 m
Dredging depth
7.39 m
Tear-out force
145 kN
Bucket width
1.37 m
Engine manuf.
Case
Engine type
6T 830
Engine power
124 kW
Displacement
8.28 l
Revolutions at max torque
1500 rpm
Max. torque
729 Nm
No. of cylinders
6
Cylinder bore x stroke
114x135 mm

More technical details, like: boom, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 9040 FAQ

When was the Case 9040 manufactured?

The Case 9040 was manufactured from 1990 to 2015.

How much does the Case 9040 weigh?

The Case 9040 weighs 24.47 tons.

What are the transport dimensions of the Case 9040 crawler excavator?

The Case 9040 crawler excavator has a transport length of 9.88 meters, a transport width of 3.38 meters, and a transport height of 3.07 meters.

What are the undercarriage specifications of the Case 9040 crawler excavator?

The Case 9040 crawler excavator has a heavy duty undercarriage with a track width of 800 mm.

What are the dredging depth and maximum horizontal reach of the Case 9040 crawler excavator?

The Case 9040 crawler excavator has a dredging depth of 7.39 meters and a maximum horizontal reach of 10.64 meters.

What is the tear-out force of the Case 9040?

The Case 9040 has a tear-out force of 145 kN.

What are the bucket specifications of the Case 9040 crawler excavator?

The Case 9040 crawler excavator has a bucket capacity ranging from 0.57 to 1.15 cubic meters and a bucket width of 1.37 meters.

How much is a Case 9040 Crawler excavator (1990u20132015) worth?

The residual value of the Case 9040 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
