9030 Case excavator specs & Dimensions (1992 - 2015)

Case 9030 is a Crawler Excavator manufactured from 1992 to 2015. It has a weight of 19.7 tons, a transport length of 9.37 meters, …

Case 9030 is a Crawler Excavator manufactured from 1992 to 2015. It has a weight of 19.7 tons, a transport length of 9.37 meters, a transport width of 3.1 meters, and a transport height of 2.92 meters. The machine features a tear-out force of 109 kN, a dredging depth of 6.6 meters, and a maximum horizontal reach of 9.67 meters. The bucket capacity ranges from a minimum of 0.48 cubic meters to a maximum of 0.96 cubic meters, with a standard capacity of 0.96 cubic meters.

Crawler Excavators Case 9030

Technical specs - 9030 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.7 t
Transport length
9.37 m
Transport width
3.1 m
Transport height
2.92 m
Bucket capacity
0.96 m³
Bucket capacity min.
0.48 m³
Bucket capacity max.
0.96 m³
Max. Reach horizontal
9.67 m
Dredging depth
6.6 m
Tear-out force
109 kN
Engine manuf.
Case
Engine type
6T 590
Engine power
96 kW

More technical details, like: undercarriage, track width, boom, bucket width, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 9030 FAQ

When was the Case 9030 manufactured?

The Case 9030 was manufactured from 1992 to 2015.

How much does the Case 9030 weigh?

The Case 9030 weighs 19.7 tons.

What are the transport dimensions of the Case 9030 crawler excavator?

The Case 9030 crawler excavator has a transport length of 9.37 meters, a transport width of 3.1 meters, and a transport height of 2.92 meters.

What are the dredging depth and maximum horizontal reach of the Case 9030 crawler excavator?

The Case 9030 crawler excavator has a dredging depth of 6.6 meters and a maximum horizontal reach of 9.67 meters.

What power rating information is available for the Case 9030 crawler excavator?

There is no power rating information available for the Case 9030 crawler excavator in the provided data.

What are the bucket capacity specifications of the Case 9030 crawler excavator?

The Case 9030 crawler excavator has a bucket capacity of 0.96 cubic meters, with a maximum capacity of 0.96 cubic meters and a minimum capacity of 0.48 cubic meters.
