MC110B Volvo MC110B Specifications & Technical Data (2006—2011)

The Volvo MC110B is a skid steer loader manufactured by Volvo from 2006 to 2011. It has a weight of 3.394 tons and a transport len…

The Volvo MC110B is a skid steer loader manufactured by Volvo from 2006 to 2011. It has a weight of 3.394 tons and a transport length of 3.576 meters. The bucket capacity is 0.38 cubic meters, with a bucket width of 1.88 meters. The maximum discharge height is 3.996 meters, and it has a travel speed of 10 km/h. The transport width is 1.836 meters, and the transport height is 2.064 meters. The lifting force is 22.83 kilonewtons, and the rated operating capacity is 2184 kilograms.

Skid Steer Loaders Volvo MC110B

Visit Volvo live at

Technical specs - MC110B Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.394 t
Rated operating capacity
2184 kg
Standard tyres
12x16.5-12PR
Bucket width
1.88 m
Bucket capacity
0.38 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.576 m
Transport width
1.836 m
Transport height
2.064 m
Travel speed
10 km/h
Max. discharge height
3.996 m
Lifting force
22.83 kN
Engine manuf.
Volvo
Engine type
D3.4A
Engine power
61.6 kW
Displacement
3.3 l
Revolutions at max torque
2400 rpm
Max. torque
305/1800 Nm
No. of cylinders
4

More technical details, like: track width, model series, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Volvo MC110B FAQ

When was the Volvo MC110B manufactured?

The Volvo MC110B was manufactured from 2006 to 2011.

How much does the Volvo MC110B skid steer loader weigh?

The Volvo MC110B skid steer loader weighs 3.39 tons.

What are the transport dimensions of the Volvo MC110B skid steer loader?

The Volvo MC110B has a transport length of 3.58 meters, a transport width of 1.84 meters, and a transport height of 2.06 meters.

What is the travel speed of the Volvo MC110B skid steer loader?

The Volvo MC110B skid steer loader has a travel speed of 10 km/h.

What are the undercarriage specifications of the Volvo MC110B skid steer loader?

The Volvo MC110B skid steer loader is equipped with standard tyres sized 12x16.5-12PR.

What is the steering mode of the Volvo MC110B skid steer loader?

The Volvo MC110B skid steer loader features all-wheel steering.

What are the power ratings of the Volvo MC110B skid steer loader?

There are no power ratings available for the Volvo MC110B skid steer loader in the provided data.

What is the material handling capacity of the Volvo MC110B skid steer loader?

The Volvo MC110B has a rated operating capacity of 2184 kg and a maximum discharge height of 4 meters.

What are the specifications of the primary work tool on the Volvo MC110B skid steer loader?

The primary work tool of the Volvo MC110B skid steer loader has a bucket capacity of 0.38 cubic meters and a bucket width of 1.88 meters.

What operator safety and support features does the Volvo MC110B have?

The Volvo MC110B is equipped with a cabin that includes ROPS for driver protection.

How much is a Volvo MC110B Skid steer loader (2006u20132011) worth?

The residual value of the Volvo MC110B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
