320 John Deere Construction 320 Specifications & Technical Data (2004—2021)

The John Deere Construction 320 is a skid steer loader manufactured by John Deere Construction from 2004 to 2021. It has a weight …

The John Deere Construction 320 is a skid steer loader manufactured by John Deere Construction from 2004 to 2021. It has a weight of 2.916 tons and a transport length of 3.195 meters. The maximum discharge height is 2.926 meters, and it has a travel speed of 10.9 km/h. The transport width is 1.773 meters, and the transport height is 1.951 meters.

Skid Steer Loaders John Deere Construction 320

Technical specs - 320 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.916 t
Standard tyres
12x16.5 10 PR SKS
Driver protection
KbR
Transport length
3.195 m
Transport width
1.773 m
Transport height
1.951 m
Travel speed
10.9 km/h
Max. discharge height
2.926 m
Model series
300
Engine manuf.
John Deere
Engine type
4024T
Engine power
49.2 kW
Displacement
2.4 l
Max. torque
149 Nm
No. of cylinders
4
Emission level
Tier II

More technical details, like: rated operating capacity, track width, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

John Deere Construction 320 FAQ

When was the John Deere Construction 320 manufactured?

The John Deere Construction 320 was manufactured from 2004 to 2021.

How much does the John Deere Construction 320 skid steer loader weigh?

The John Deere Construction 320 skid steer loader weighs 2.92 tons.

What are the transport dimensions of the John Deere Construction 320 skid steer loader?

The John Deere Construction 320 has a transport length of 3.2 meters, a transport width of 1.77 meters, and a transport height of 1.95 meters.

What is the travel speed of the John Deere Construction 320 skid steer loader?

The John Deere Construction 320 has a travel speed of 10.9 km/h.

What are the standard tyres of the John Deere Construction 320 skid steer loader?

The John Deere Construction 320 skid steer loader has standard tyres sized 12x16.5 10 PR SKS.

What is the maximum discharge height of the John Deere Construction 320?

The maximum discharge height of the John Deere Construction 320 is 2.93 meters.

What driver protection does the John Deere Construction 320 have?

The John Deere Construction 320 has driver protection in the form of a cabin with ROPS.

How much is a John Deere Construction 320 Skid steer loader (2004u20132021) worth?

The residual value of the John Deere Construction 320 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
