TL 12 R2 Takeuchi TL 12 R2 Specifications & Technical Data (2017—2026)

The Takeuchi TL 12 R2 is a skid steer loader manufactured by Takeuchi since 2017. It has a weight of 5.58 tons and a transport len…

The Takeuchi TL 12 R2 is a skid steer loader manufactured by Takeuchi since 2017. It has a weight of 5.58 tons and a transport length of 4.045 meters. The bucket width is 2.03 meters, and the maximum discharge height is 3.3 meters. It has a travel speed of 11.8 km/h, with a transport width of 1.96 meters and a transport height of 2.33 meters. The track width is 450 millimeters, and the rated operating capacity is 1350 kilograms.

Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2
Skid Steer Loaders Takeuchi TL 12 R2

Technical specs - TL 12 R2 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.58 t
Rated operating capacity
1350 kg
Track width
450 mm
Bucket width
2.03 m
Driver protection
Kb
Transport length
4.045 m
Transport width
1.96 m
Transport height
2.33 m
Travel speed
11.8 km/h
Max. discharge height
3.3 m
Model series
TL
Engine manuf.
Kubota
Engine type
V3800T-IF4B-Turbo Intercooled
Engine power
83 kW
Displacement
3.8 l
Revolutions at max torque
1500 rpm
Max. torque
379 Nm
Emission level
Tier 4/stage IV

More technical details, like: standard tyres, bucket capacity, steering mode, lifting force, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Takeuchi TL 12 R2 FAQ

When was the Takeuchi TL 12 R2 manufactured?

The Takeuchi TL 12 R2 was first produced in 2017.

How much does the Takeuchi TL 12 R2 skid steer loader weigh?

The Takeuchi TL 12 R2 skid steer loader weighs 5.58 tons.

What are the transport dimensions of the Takeuchi TL 12 R2 skid steer loader?

The Takeuchi TL 12 R2 has a transport length of 4.05 meters, a transport width of 1.96 meters, and a transport height of 2.33 meters.

What is the travel speed of the Takeuchi TL 12 R2 skid steer loader?

The Takeuchi TL 12 R2 has a travel speed of 11.8 km/h.

What is the track width of the Takeuchi TL 12 R2 skid steer loader?

The Takeuchi TL 12 R2 skid steer loader has a track width of 450 mm.

What is the material handling capacity of the Takeuchi TL 12 R2 skid steer loader?

The Takeuchi TL 12 R2 has a rated operating capacity of 1350 kg and a maximum discharge height of 3.3 meters.

What is the bucket width of the Takeuchi TL 12 R2 skid steer loader?

The bucket width of the Takeuchi TL 12 R2 skid steer loader is 2.03 meters.

What operator safety features does the Takeuchi TL 12 R2 have?

The Takeuchi TL 12 R2 has a cabin for driver protection.
