2054 B Mustang 2054 B Specifications & Technical Data (2011—2016)

The Mustang 2054 B Skid Steer Loader, manufactured from 2011 to 2016, weighs 2.95 tons and has a transport length of 3.11 meters. …

The Mustang 2054 B Skid Steer Loader, manufactured from 2011 to 2016, weighs 2.95 tons and has a transport length of 3.11 meters. It is equipped with a bucket capacity of 0.43 cubic meters and a bucket width of 1.76 meters. With a maximum discharge height of 2.34 meters, it has a transport width of 1.56 meters and a transport height of 1.97 meters. This construction machine has a rated operating capacity of 748 kilograms.

Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B
Skid Steer Loaders Mustang 2054 B

Technical specs - 2054 B Mustang

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.95 t
Rated operating capacity
748 kg
Standard tyres
12.00x16.5
Bucket width
1.76 m
Bucket capacity
0.43 m³
Driver protection
Kb
Steering mode
AL
Transport length
3.11 m
Transport width
1.56 m
Transport height
1.97 m
Travel speed
11.5 km/h
Max. discharge height
2.34 m
Engine manuf.
Yanmar
Engine type
4TNV88
Engine power
36 kW
Displacement
2.19 l
Revolutions at max torque
3000 rpm
No. of cylinders
4
Emission level
IIIa

More technical details, like: track width, lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available...

More technical details, like: track width, lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, tipping load, operating capacity, speed - maximum, pump type, pump flow, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Mustang 2054 B FAQ

When was the Mustang 2054 B manufactured?

The Mustang 2054 B was manufactured from 2011 to 2016.

How much does the Mustang 2054 B skid steer loader weigh?

The Mustang 2054 B skid steer loader weighs 2.95 tons.

What are the transport dimensions of the Mustang 2054 B skid steer loader?

The Mustang 2054 B has a transport length of 3.11 meters, a transport width of 1.56 meters, and a transport height of 1.97 meters.

What is the travel speed of the Mustang 2054 B skid steer loader?

The Mustang 2054 B skid steer loader has a travel speed of 11.5 km/h.

What are the undercarriage specifications of the Mustang 2054 B skid steer loader?

The Mustang 2054 B skid steer loader has standard tyres sized 12.00x16.5.

What is the steering mode of the Mustang 2054 B?

The Mustang 2054 B has an all-wheel steering mode.

What is the material handling capacity of the Mustang 2054 B skid steer loader?

The Mustang 2054 B skid steer loader has a rated operating capacity of 748 kg and a maximum discharge height of 2.34 meters.

What are the bucket specifications of the Mustang 2054 B skid steer loader?

The Mustang 2054 B skid steer loader has a bucket capacity of 0.43 cubic meters and a bucket width of 1.76 meters.

What operator safety features does the Mustang 2054 B have?

The Mustang 2054 B has a cabin for driver protection.
