270-II John Deere Construction 270-II Specifications & Technical Data (2003—2021)

The John Deere Construction 270-II is a skid steer loader manufactured from 2003 to 2021. It has a weight of 3.856 tons and a tran…

The John Deere Construction 270-II is a skid steer loader manufactured from 2003 to 2021. It has a weight of 3.856 tons and a transport length of 3.504 meters. The maximum discharge height is 3.226 meters, and it can travel at a speed of 19.3 km/h. The transport width is 1.935 meters, and the transport height is 2.105 meters.

Skid Steer Loaders John Deere Construction 270-II

Technical specs - 270-II John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.856 t
Driver protection
KbR
Transport length
3.504 m
Transport width
1.935 m
Transport height
2.105 m
Travel speed
19.3 km/h
Max. discharge height
3.226 m
Model series
II
Engine manuf.
John Deere
Engine type
4045D
Engine power
61.2 kW
Displacement
4.6 l
No. of cylinders
4

More technical details, like: rated operating capacity, track width, standard tyres, bucket width, bucket capacity, steering mode, lifting force, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

John Deere Construction 270-II FAQ

When was the John Deere Construction 270-II manufactured?

The John Deere Construction 270-II was manufactured from 2003 to 2021.

How much does the John Deere Construction 270-II skid steer loader weigh?

The John Deere Construction 270-II skid steer loader weighs 3.86 tons.

What are the transport dimensions of the John Deere Construction 270-II skid steer loader?

The John Deere Construction 270-II has a transport length of 3.5 meters, a transport width of 1.94 meters, and a transport height of 2.11 meters.

What is the travel speed of the John Deere Construction 270-II skid steer loader?

The John Deere Construction 270-II skid steer loader has a travel speed of 19.3 km/h.

What is the maximum discharge height of the John Deere Construction 270-II?

The John Deere Construction 270-II has a maximum discharge height of 3.23 meters.

What operator safety and support features does the John Deere Construction 270-II have?

The John Deere Construction 270-II is equipped with a cabin that includes ROPS for driver protection.

How much is a John Deere Construction 270-II Skid steer loader (2003u20132021) worth?

The residual value of the John Deere Construction 270-II depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
