325T JCB 325T Specifications & Technical Data (2017—2020)

The JCB 325T is a skid steer loader manufactured by JCB from 2017 to 2020. It has a weight of 5.61 tons and a transport length of …

The JCB 325T is a skid steer loader manufactured by JCB from 2017 to 2020. It has a weight of 5.61 tons and a transport length of 3.8 meters. The bucket capacity is 0.64 cubic meters, with a bucket width of 2.13 meters. The maximum discharge height is 2.28 meters. The transport width is 1.9 meters, and the transport height is 2.08 meters. The lifting force is 29.1 kilonewtons, and the track width is 450 millimeters. The rated operating capacity is 2074 kilograms.

Skid Steer Loaders JCB 325T

Visit JCB live at

Technical specs - 325T JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.61 t
Rated operating capacity
2074 kg
Track width
450 mm
Bucket width
2.13 m
Bucket capacity
0.64 m³
Driver protection
KbR
Transport length
3.8 m
Transport width
1.9 m
Transport height
2.08 m
Travel speed
9.2 km/h
Max. discharge height
2.28 m
Lifting force
29.1 kN
Engine manuf.
JCB
Engine type
EcoMax TCAE
Engine power
55 kW
Displacement
4.4 l
Revolutions at max torque
1300 rpm
Max. torque
400 Nm
Cylinder bore x stroke
103x132 mm

More technical details, like: standard tyres, steering mode, model series, dimension lxwxh, no. of cylinders, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

JCB 325T FAQ

When was the JCB 325T skid steer loader manufactured?

The JCB 325T skid steer loader was manufactured from 2017 to 2020.

How much does the JCB 325T skid steer loader weigh?

The JCB 325T skid steer loader weighs 5.61 tons.

What are the transport dimensions of the JCB 325T skid steer loader?

The JCB 325T skid steer loader has a transport length of 3.8 meters, a transport width of 1.9 meters, and a transport height of 2.08 meters.

What is the travel speed of the JCB 325T skid steer loader?

The JCB 325T skid steer loader has a travel speed of 9.2 km/h.

What is the track width of the JCB 325T skid steer loader?

The JCB 325T skid steer loader has a track width of 450 mm.

What is the lifting force of the JCB 325T skid steer loader?

The JCB 325T skid steer loader has a lifting force of 29.1 kN.

What is the material handling capacity of the JCB 325T skid steer loader?

The JCB 325T skid steer loader has a rated operating capacity of 2074 kilograms.

What are the specifications of the bucket on the JCB 325T skid steer loader?

The bucket on the JCB 325T skid steer loader has a capacity of 0.64 cubic meters and a width of 2.13 meters.

What operator safety and support features does the JCB 325T have?

The JCB 325T is equipped with a cabin that includes ROPS (Roll Over Protective Structure) for driver protection.

How much is a JCB 325T Skid steer loader (2017u20132020) worth?

The residual value of the JCB 325T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
