190 JCB 190 Specifications & Technical Data (2013—2017)

The JCB 190 is a skid steer loader manufactured by JCB from 2013 to 2017. It has a weight of 3.2 tons and a transport length of 3.…

The JCB 190 is a skid steer loader manufactured by JCB from 2013 to 2017. It has a weight of 3.2 tons and a transport length of 3.56 meters. The bucket capacity is 0.41 cubic meters, with a bucket width of 1.73 meters. The maximum discharge height is 2.26 meters, and it has a travel speed of 12 km/h. The transport width is 1.6 meters, and the transport height is 1.98 meters. The rated operating capacity is 862 kilograms.

Skid Steer Loaders JCB 190

Visit JCB live at

Technical specs - 190 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.2 t
Rated operating capacity
862 kg
Standard tyres
10x16.5-8 PR
Bucket width
1.73 m
Bucket capacity
0.41 m³
Driver protection
KbR
Steering mode
AL
Transport length
3.56 m
Transport width
1.6 m
Transport height
1.98 m
Travel speed
12 km/h
Max. discharge height
2.26 m
Engine manuf.
Kohler
Engine type
KDI2054TCR
Engine power
46 kW
Dimension lxwxh
704.3x523.2x719.5 mm
Displacement
2.482 l
Max. torque
300/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
88x102 mm

More technical details, like: track width, lifting force, model series, revolutions at max torque, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer...

More technical details, like: track width, lifting force, model series, revolutions at max torque, emission level, lift geometry, access, rating standard - rops, rating standard - fops, telematics available, security system available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, torque, transmission type, drive chain rating [ansi], tyre size, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, lift height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - lift, breakout - bucket, pump type, hydraulic power, hydraulic power - option, pump flow, system pressure, self levelling, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

JCB 190 FAQ

When was the JCB 190 skid steer loader manufactured?

The JCB 190 skid steer loader was manufactured from 2013 to 2017.

How much does the JCB 190 skid steer loader weigh?

The JCB 190 skid steer loader weighs 3.2 tons.

What are the transport dimensions of the JCB 190 skid steer loader?

The JCB 190 skid steer loader has a transport length of 3.56 meters, a transport width of 1.6 meters, and a transport height of 1.98 meters.

What is the travel speed of the JCB 190 skid steer loader?

The JCB 190 skid steer loader has a travel speed of 12 km/h.

What is the standard tyre specification of the JCB 190 skid steer loader?

The JCB 190 skid steer loader has standard tyres sized 10x16.5-8 PR.

What is the steering mode of the JCB 190 skid steer loader?

The JCB 190 skid steer loader has an all-wheel steering mode.

What is the material handling capacity of the JCB 190 skid steer loader?

The JCB 190 skid steer loader has a rated operating capacity of 862 kilograms.

What are the specifications of the primary work tool bucket on the JCB 190 skid steer loader?

The JCB 190 skid steer loader has a bucket with a capacity of 0.41 cubic meters and a width of 1.73 meters.

What operator safety and support features does the JCB 190 skid steer loader have?

The JCB 190 skid steer loader features a cabin with ROPS for driver protection.

How much is a JCB 190 Skid steer loader (2013u20132017) worth?

The residual value of the JCB 190 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
