SL 5640 DXT Gehl SL 5640 DXT Specifications & Technical Data (2004—2007)

The Gehl SL 5640 DXT is a skid steer loader manufactured by Gehl from 2004 to 2007. It has a weight of 3.34 tons and a transport l…

The Gehl SL 5640 DXT is a skid steer loader manufactured by Gehl from 2004 to 2007. It has a weight of 3.34 tons and a transport length of 3.33 meters. The bucket capacity is 0.43 cubic meters, and the transport width is 1.7 meters. The transport height is 2.03 meters. It has a rated operating capacity of 930 kilograms.

Skid Steer Loaders Gehl SL 5640 DXT

Technical specs - SL 5640 DXT Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.34 t
Rated operating capacity
930 kg
Standard tyres
12.00X16.5
Bucket capacity
0.43 m³
Transport length
3.33 m
Transport width
1.7 m
Transport height
2.03 m
Travel speed
13.5 km/h
Model series
SL
Engine manuf.
Deutz
Engine type
BF4M2011
Engine power
60 kW

More technical details, like: track width, bucket width, driver protection, steering mode, max. discharge height, lifting force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: track width, bucket width, driver protection, steering mode, max. discharge height, lifting force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, lift geometry, access, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, tyre size, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, wheelbase, rear departure angle, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - rear corner, turning radius - bucket corner, fuel tank, heaped capacity, tipping load, operating capacity, speed - maximum, breakout - bucket, pump flow, system pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Gehl SL 5640 DXT FAQ

When was the Gehl SL 5640 DXT manufactured?

The Gehl SL 5640 DXT was manufactured from 2004 to 2007.

How much does the Gehl SL 5640 DXT weigh?

The Gehl SL 5640 DXT weighs 3.34 tons.

What are the transport dimensions of the Gehl SL 5640 DXT skid steer loader?

The Gehl SL 5640 DXT has a transport length of 3.33 meters, a transport width of 1.7 meters, and a transport height of 2.03 meters.

What is the travel speed of the Gehl SL 5640 DXT skid steer loader?

The Gehl SL 5640 DXT has a travel speed of 13.5 km/h.

What are the standard tyre specifications of the Gehl SL 5640 DXT skid steer loader?

The standard tyres of the Gehl SL 5640 DXT skid steer loader are sized 12.00X16.5.

What is the material handling capacity of the Gehl SL 5640 DXT skid steer loader?

The Gehl SL 5640 DXT skid steer loader has a rated operating capacity of 930 kg.

What is the bucket capacity of the Gehl SL 5640 DXT skid steer loader?

The Gehl SL 5640 DXT skid steer loader has a bucket capacity of 0.43 cubic meters.

How much is a Gehl SL 5640 DXT Skid steer loader (2004u20132007) worth?

The residual value of the Gehl SL 5640 DXT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
