R165 Gehl R165 Specifications & Technical Data (2026—2026)

Weight: 2.796t – Rated operating capacity: 816.5kg – Standard tyres: 10.00 x 16.5 HD – Bucket width: 1.562m – Driver protection: KbR – Transport length: 2.385m

Skid Steer Loaders Gehl R165
Skid Steer Loaders Gehl R165
Skid Steer Loaders Gehl R165
Skid Steer Loaders Gehl R165
Skid Steer Loaders Gehl R165
Skid Steer Loaders Gehl R165

Technical specs - R165 Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.796 t
Rated operating capacity
816.5 kg
Standard tyres
10.00 x 16.5 HD
Bucket width
1.562 m
Driver protection
KbR
Transport length
2.385 m
Transport width
1.58 m
Transport height
1.956 m
Travel speed
12.6 km/h
Max. discharge height
2.38 m
Model series
R
Engine manuf.
Yanmar
Engine type
4TNV98C-NMS2V
Engine power
51.7 kW
Revolutions at max torque
1625 rpm
Max. torque
241 Nm
No. of cylinders
4
Emission level
Stage V

More technical details, like: track width, bucket capacity, steering mode, lifting force, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)
