246D Caterpillar 246D Specifications & Technical Data (2016—2026)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - 246D Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.37 t
- Rated operating capacity
- 975 kg
- Standard tyres
- 12x16.5
- Bucket width
- 1.68 m
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.71 m
- Transport width
- 1.68 m
- Transport height
- 2.11 m
- Travel speed
- 17.7 km/h
- Max. discharge height
- 2.46 m
- Lifting force
- 32.71 kN
- Engine manuf.
- Caterpillar
- Engine type
- C3.3B DIT
- Engine power
- 54.9 kW
- Displacement
- 3.3 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 265 Nm
- Cylinder bore x stroke
- 94x120 mm
- Emission level
- Tier 4 f. IIIB
More technical details, like: track width, bucket capacity, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download specalog and datasheets (PDF)
