T870 Bobcat T870 Specifications & Technical Data (2011—2018)

The Bobcat T870 is a skid steer loader manufactured by Bobcat from 2011 to 2018. It has a weight of 5.75 tons and a transport leng…

The Bobcat T870 is a skid steer loader manufactured by Bobcat from 2011 to 2018. It has a weight of 5.75 tons and a transport length of 3.91 meters. The bucket width is 2.13 meters, and it has a maximum discharge height of 2.728 meters. The transport width is 2.11 meters, and the transport height is 2.12 meters. The track width is 450 millimeters, and it has a rated operating capacity of 1584 kilograms.

Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870
Skid Steer Loaders Bobcat T870

Visit Bobcat live at

Technical specs - T870 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.75 t
Rated operating capacity
1584 kg
Track width
450 mm
Bucket width
2.13 m
Driver protection
KbR
Transport length
3.91 m
Transport width
2.11 m
Transport height
2.12 m
Travel speed
18.3 km/h
Max. discharge height
2.728 m
Model series
T
Engine manuf.
Kubota
Engine type
V3800DI-TE3
Engine power
74 kW
Displacement
3.77 l
Revolutions at max torque
1600 rpm

More technical details, like: standard tyres, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access...

More technical details, like: standard tyres, bucket capacity, steering mode, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, lift geometry, access, suspension seat, telematics available, security system available, engine manufacturer, engine model, number of cylinders, aspiration, rated speed, engine output - gross, rated speed - torque, torque, transmission type, drive method, track rollers, track shoe width, length - no bucket, length - with bucket, width - no bucket, width - with bucket, height - top of cab, ground clearance, track length on ground, height to hinge pin, dump angle, dump height - maximum, reach - max dump height, turning radius - bucket corner, fuel tank, tipping load, operating capacity, ground bearing pressure, speed - maximum, hydraulic power, hydraulic power - option, pump flow, pump flow - option, operating weight are available in the full technical specs.

Basic model with ROPS cabin and std. shovel with teeth

Special equipment

Diesel particulate filter
No
LPG motor
No
Burglar proof system
No

Download datasheets (PDF)

Bobcat T870 FAQ

When was the Bobcat T870 manufactured?

The Bobcat T870 was manufactured from 2011 to 2018.

How much does the Bobcat T870 skid steer loader weigh?

The Bobcat T870 skid steer loader weighs 5.75 tons.

What are the transport dimensions of the Bobcat T870 skid steer loader?

The Bobcat T870 has a transport length of 3.91 meters, a transport width of 2.11 meters, and a transport height of 2.12 meters.

What is the travel speed of the Bobcat T870 skid steer loader?

The Bobcat T870 has a travel speed of 18.3 km/h.

What is the track width of the Bobcat T870 skid steer loader?

The Bobcat T870 skid steer loader has a track width of 450 mm.

What is the material handling capacity of the Bobcat T870 skid steer loader?

The Bobcat T870 has a rated operating capacity of 1584 kg and a maximum discharge height of 2.73 meters.

What is the bucket width of the Bobcat T870 skid steer loader?

The Bobcat T870 skid steer loader has a bucket width of 2.13 meters.

What operator safety and support features does the Bobcat T870 have?

The Bobcat T870 is equipped with a cabin that includes ROPS for driver protection.

How much is a Bobcat T870 Skid steer loader (2011u20132018) worth?

The residual value of the Bobcat T870 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
