S770 Bobcat S770 Specifications & Technical Data (2011—2017)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Bobcat live at
Technical specs - S770 Bobcat
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.66 t
- Rated operating capacity
- 1569 kg
- Standard tyres
- 12.00-16.5 12 PR
- Bucket width
- 1.88 m
- Bucket capacity
- 1.4 m³
- Driver protection
- KbR
- Transport length
- 3.63 m
- Transport width
- 1.88 m
- Transport height
- 2.06 m
- Travel speed
- 11.6 km/h
- Max. discharge height
- 3.27 m
- Lifting force
- 30.4 kN
- Model series
- S
- Engine manuf.
- Kubota
- Engine type
- V3300-DI-T
- Engine power
- 58 kW
- Displacement
- 3.32 l
- Revolutions at max torque
- 2400 rpm
More technical details, like: track width, steering mode, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
