Technical specs - S630 Bobcat
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.45 t
- Rated operating capacity
- 1040 kg
- Standard tyres
- 12x16.5 12–ply
- Bucket width
- 1.88 m
- Bucket capacity
- 0.91 m³
- Driver protection
- KbR
- Steering mode
- AL
- Transport length
- 3.47 m
- Transport width
- 1.83 m
- Transport height
- 2.06 m
- Travel speed
- 11.4 km/h
- Max. discharge height
- 2.37 m
- Model series
- S
- Engine manuf.
- Bobcat
- Engine type
- D24
- Engine power
- 56 kW
- Displacement
- 2.392 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 283.9 Nm
- No. of cylinders
- 4
- Emission level
- III B
More technical details, like: track width, lifting force, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. shovel with teeth
Special equipment
- Diesel particulate filter
-
No
- LPG motor
-
No
- Burglar proof system
-
No
Download datasheets (PDF)
Bobcat S630 FAQ
How much does the Bobcat S630 weigh?
What are the transport dimensions of the Bobcat S630 skid steer loader?
What is the travel speed of the Bobcat S630 skid steer loader?
What are the undercarriage specifications of the Bobcat S630 skid steer loader?
What is the steering mode of the Bobcat S630 skid steer loader?
What is the material handling capacity of the Bobcat S630 skid steer loader?
What are the specifications of the primary work tool bucket on the Bobcat S630?
What operator safety and support features does the Bobcat S630 have?
How much is a Bobcat S630 Skid steer loader (2017u20132021) worth?
