YC15-8 Yuchai excavator specs & dimensions (2020 - 2026)

Yuchai YC15-8 is a mini excavator manufactured since 2020, with a weight of 1.73 tons. It features a track width of 230 mm, a tran…

Yuchai YC15-8 is a mini excavator manufactured since 2020, with a weight of 1.73 tons. It features a track width of 230 mm, a transport length of 3.67 meters, and a transport height of 2.31 meters. The machine has a tear-out force of 11 kN, a dredging depth of 1.8 meters, and a maximum horizontal reach of 3.45 meters. The bucket width is 0.4 meters with a capacity of 0.04 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Yuchai YC15-8

Technical specs - YC15-8 Yuchai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.73 t
Transport length
3.67 m
Transport height
2.31 m
Bucket capacity
0.04 m³
Bucket width
0.4 m
Track width
230 mm
Driver protection
FD/Kb
Max. Reach horizontal
3.45 m
Dredging depth
1.8 m
Tear-out force
11 kN
Engine manuf.
Perkins
Engine type
N/A
Engine power
14.7 kW

More technical details, like: transport width, bucket capacity min., bucket capacity max., standard tyres, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yuchai YC15-8 FAQ

When was the Yuchai YC15-8 manufactured?

The Yuchai YC15-8 was first produced in 2020.

How much does the Yuchai YC15-8 weigh?

The Yuchai YC15-8 weighs 1.73 tons.

What are the transport dimensions of the Yuchai YC15-8 mini excavator?

The Yuchai YC15-8 has a transport length of 3.67 meters and a transport height of 2.31 meters.

What is the track width of the Yuchai YC15-8 mini excavator's undercarriage?

The Yuchai YC15-8 mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Yuchai YC15-8 mini excavator?

The Yuchai YC15-8 mini excavator has a dredging depth of 1.8 meters and a maximum horizontal reach of 3.45 meters.

What is the tear-out force of the Yuchai YC15-8 mini excavator?

The Yuchai YC15-8 mini excavator has a tear-out force of 11 kN.

What are the specifications of the primary work tool on the Yuchai YC15-8 mini excavator?

The primary work tool of the Yuchai YC15-8 mini excavator has a bucket capacity of 0.04 cubic meters and a bucket width of 0.4 meters.

What operator safety and support features does the Yuchai YC15-8 offer?

The Yuchai YC15-8 offers operator protection through a canopy and a cabin.
